48 Rockwell Automation Publication 5069-UM007A-EN-P - February 2019
Appendix A Compact 5000 EtherNet/IP Adapter Status Indicators
Table 4 describe the possible messages on the 4-character display for a
5069-AEN2TR adapter.
Table 4 - Messages on 4-character Display
Message Type Example Message on 4-character Display Description
TEST TEST Message appears while power-up tests run.
PASS PASS Message appears when power-up tests complete.
Embedded software version Rev 2.003 Message appears once, after the power-up tests complete
successfully.
OK OK The first message in the scrolling message display. Message scrolls
continuously during operation.
Port Down Link 2 - Port Down Message appears when an EtherNet/IP port does not have a
connection. Message scrolls continuously during operation.
Port Rate/Duplex State Port 1 - 1Gb/FULL The current port rate and duplex state. Message scrolls continuously
during operation. If not connected to a 1 Gb switch, the message
shows 100/FULL.
IP Address 192.168.1.17 The IP address of the adapter. Message scrolls continuously during
operation.
Link Disabled Port 2 - Link Disabled Message appears when you have disabled an EtherNet/IP port.
Message scrolls continuously during operation.
Duplicate IP Duplicate IP - 00:00:BC:02:34:B4 Message appears when the adapter detects a device with the same IP
address on the network. The message shows the MAC ID of the device
with the duplicate IP address. Message scrolls continuously during
operation.
Fault Cycle power to unit. Message appears, and scrolls continuously, during a fault.
