Chapter 6 Micro870 Controller Distributed Network Protocol
Object Flags for Binary Input
Bit Offset Name Description
0ONLINE
0 when the controller is or was in Non-executing mode.
1 when the controller is or was in Executing mode and the configuration file
does not exist.
May be 1 when the controller is or was in Executing mode and the
configuration file exists.
1 RESTART Always 0. Not used.
2 COMM_LOST Always 0. Not used.
3 REMOTE_FORCED Always 0. Not used.
4 LOCAL_FORCED Always 0. Not used.
5 CHATTER_FILTER Always 0. Not used.
6 Reserved Always 0. Not used.
7 STATE Reflects point state of Binary Input point.
Object Flags for Double Binary Input
Bit Offset Name Description
0ONLINE
0 when the controller is or was in Non-executing mode.
1 when the controller is or was in Executing mode and the configuration file
does not exist.
May be 1 when the controller is or was in Executing mode and the
configuration file exists.
1 RESTART Always 0. Not used.
2 COMM_LOST Always 0. Not used.
3 REMOTE_FORCED Always 0. Not used.
4 LOCAL_FORCED Always 0. Not used.
5 CHATTER_FILTER Always 0. Not used.
6 STATE Reflects point state of Double-bit Binary Input point. Double-bit LSB.
7 STATE Reflects point state of Double-bit Binary Input point. Double-bit MSB
Object Flags for Binary Output
Bit Offset Name Description
0ONLINE
0 when the controller is or was in Non-executing mode.
1 when the controller is or was in Executing mode and the configuration file
does not exist.
May be 1 when the controller is in Executing mode and the configuration file
exists.
1 RESTART Always 0. Not used.
2 COMM_LOST Always 0. Not used.
3 REMOTE_FORCED Always 0. Not used.
4 LOCAL_FORCED Always 0. Not used.
5 Reserved Always 0. Not used.
6 Reserved Always 0. Not used.
7 STATE Reflects point state of Binary Output point.
