Chapter 6 Micro870 Controller Distributed Network Protocol
20 6 Counter – 16-bit without flag
7 (freeze)
8 (freeze noack)
9 (freeze clear)
10 (frz. cl. noack)
06 (no range, or all)
21 0 Frozen Counter – Any Variation 1 (read)
00, 01 (start-stop)
06 (no range, or all)
21 1 Frozen Counter – 32-bit with flag
1 (read) 06 (no range, or all) 129 (response) 00, 01 (start-stop)
21 2 Frozen Counter – 16-bit with flag
1 (read)
00, 01 (start-stop)
06 (no range, or all)
129 (response) 00, 01 (start-stop)
21 5
Frozen Counter – 32-bit with flag and
time
1 (read)
00, 01 (start-stop)
06 (no range, or all)
129 (response) 00, 01 (start-stop)
21 6
Frozen Counter – 16-bit with flag and
time
1 (read)
00, 01 (start-stop)
06 (no range, or all)
129 (response) 00, 01 (start-stop)
21 9 Frozen Counter – 32-bit without flag
1 (read)
00, 01 (start-stop)
06 (no range, or all)
129 (response) 00, 01 (start-stop)
21 10 Frozen Counter – 16-bit without flag 1 (read)
00, 01 (start-stop)
06 (no range, or all)
129 (response) 00, 01 (start-stop)
22 0 Counter Event – Any Variation 1 (read)
06 (no range, or all)
07, 08 (limited qty)
22 1 Counter Event – 32-bit with flag
1 (read)
06 (no range, or all)
07, 08 (limited qty)
129 (response)
130 (unsol. resp)
17, 28 (index)
22 2 Counter Event – 16-bit with flag 1 (read)
06 (no range, or all)
07, 08 (limited qty)
129 (response)
130 (unsol. resp)
17, 28 (index)
22 5
Counter Event – 32-bit with flag and
time
1 (read)
06 (no range, or all)
07, 08 (limited qty)
129 (response)
130 (unsol. resp)
17, 28 (index)
22 6
Counter Event – 16-bit with flag and
time
1 (read)
06 (no range, or all)
07, 08 (limited qty)
129 (response)
130 (unsol. resp)
17, 28 (index)
23 0 Frozen Counter Event – Any Variation 1 (read)
06 (no range, or all)
07, 08 (limited qty)
23 1 Frozen Counter Event – 32-bit with flag
1 (read)
06 (no range, or all)
07, 08 (limited qty)
129 (response)
130 (unsol. resp)
17, 28 (index)
23 2 Frozen Counter Event – 16-bit with flag
1 (read)
06 (no range, or all)
07, 08 (limited qty)
129 (response)
130 (unsol. resp)
17, 28 (index)
23 5
Frozen Counter Event – 32-bit with flag
and time
1 (read)
06 (no range, or all)
07, 08 (limited qty)
129 (response)
130 (unsol. resp)
17, 28 (index)
23 6
Frozen Counter Event – 16-bit with flag
and time
1 (read)
06 (no range, or all)
07, 08 (limited qty)
129 (response)
130 (unsol. resp)
17, 28 (index)
30 0 Analog Input – Any Variation 1 (read)
00, 01 (start-stop)
06 (no range, or all)
30 1 Analog Input – 32-bit with flag
1 (read)
00, 01 (start-stop)
06 (no range, or all)
129 (response) 00, 01 (start-stop)
30 2 Analog Input – 16-bit with flag
1 (read)
00, 01 (start-stop)
06 (no range, or all)
129 (response) 00, 01 (start-stop)
30 3 Analog Input – 32-bit without flag 1 (read)
00, 01 (start-stop)
06 (no range, or all)
129 (response) 00, 01 (start-stop)
30 4 Analog Input – 16-bit without flag
1 (read)
00, 01 (start-stop)
06 (no range, or all)
129 (response) 00, 01 (start-stop)
30 5
Analog Input – Single-prec flt-pt with
flag
1 (read)
00, 01 (start-stop)
06 (no range, or all)
129 (response) 00, 01 (start-stop)
32 0 Analog Input Event – Any Variation 1 (read)
06 (no range, or all)
07, 08 (limited qty)
32 1
Analog Input Event – 32-bit without
time
1 (read)
06 (no range, or all)
07, 08 (limited qty)
129 (response)
130 (unsol. resp)
17, 28 (index)
32 2
Analog Input Event – 16-bit without
time
1 (read)
06 (no range, or all)
07, 08 (limited qty)
129 (response)
130 (unsol. resp)
17, 28 (index)
32 3 Analog Input Event – 32-bit with time
1 (read)
06 (no range, or all)
07, 08 (limited qty)
129 (response)
130 (unsol. resp)
17, 28 (index)
Table 12 - Implementation Table for Micro870 controllers (Continued)
