20 Rockwell Automation Publication 2080-UM002N-EN-E - November 2022
Chapter 1 Hardware Overview
You can order replacement terminal blocks, catalog number 2080-RPL24RTB,
separately.
Table 1 - Micro830 Controllers – Number and Types of Inputs/Outputs
Catalog Number
Inputs Outputs
PTO Support HSC Support
110V AC 24V DC/V AC Relay 24V Sink 24V Source
2080-LC30-10QWB – 6 4 – – – 2
2080-LC30-10QVB – 6 – 4 – 1 2
2080-LC30-16AWB 10 – 6 – – – –
2080-LC30-16QWB – 10 6 – – – 2
2080-LC30-16QVB – 10 – 6 – 1 2
2080-LC30-24QWB – 14 10 – – – 4
2080-LC30-24QVB – 14 – 10 – 2 4
2080-LC30-24QBB – 14 – – 10 2 4
2080-LC30-48AWB 28 – 20 – – – –
2080-LC30-48QWB – 28 20 – – – 6
2080-LC30-48QVB – 28 – 20 – 3 6
2080-LC30-48QBB – 28 – – 20 3 6
Table 2 - Micro850 Controllers – Number and Types of Inputs/Outputs
Catalog Number
Inputs Outputs
PTO Support HSC Support
120V AC 24V DC/V AC Relay 24V Sink 24V Source
2080-LC50-24AWB 14 – 10 – – – –
2080-L50E-24AWB 14 – 10 – – – –
2080-LC50-24QWB – 14 10 – – – 4
2080-L50E-24QWB – 14 10 – – – 4
2080-LC50-24QVB – 14 – 10 – 2 4
2080-L50E-24QVB – 14 – 10 – 2 4
2080-LC50-24QBB – 14 – – 10 2 4
2080-L50E-24QBB – 14 – – 10 2 4
2080-LC50-48AWB 28 – 20 – – – –
2080-L50E-48AWB 28 – 20 – – – –
2080-LC50-48QWB – 28 20 – – – 6
2080-L50E-48QWB – 28 20 – – – 6
2080-LC50-48QWBK –2820––– 6
2080-L50E-48QWBK –2820––– 6
2080-LC50-48QVB – 28 – 20 – 3 6
2080-L50E-48QVB – 28 – 20 – 3 6
2080-LC50-48QBB – 28 – – 20 3 6
2080-L50E-48QBB – 28 – – 20 3 6
