Rockwell Automation Publication 2080-UM002N-EN-E - November 2022 231
Chapter 11 Controller Security
6. While connected to the controller and being in the MEMBAK-RTC properties, make sure
that the controller is changed to Program Mode and click “Backup to Memory Module”
under Memory Module Settings. Select Yes to download the program into the Memory
Module. A window should pop up stating that the operation has been completed
successfully.
Restore the Project
To restore the project from the memory module to the controller, follow these steps:
1. While connected to the controller and being in the MEMBAK-RTC properties, make sure
that the controller is changed to Program Mode and click “Restore from Memory Module”
under Memory Module Settings. Select Yes to download the program into the controller.
A window should pop up stating that the operation has been completed successfully.
Using the Memory Module to Copy a Project to Multiple Controllers
You can use the memory module to download a project to multiple controllers without
connecting them to a PC with Connected Components Workbench software installed. To do
this:
1. Back up a project with “Load Always” option enabled.
2. Remove the module and plug it into a different controller.
3. Cycle the power. Observe the Status LED on the module lights up for a few seconds
while the project is being downloaded from the module to the controller.
4. When the operation is finished you can unplug the module and leave the slot empty, or
plug in a different MEMBAK-RTC module if you want to use the RTC functionality.
IMPORTANT The Password Mismatch status must be at “False”, this means that the
Controller and Backup project have the same security condition.
If the status is “True” then the Controller will not load from the Memory
module as the security condition is mismatched.
