258 Rockwell Automation Publication 2080-UM002N-EN-E - November 2022
Chapter 12 Using microSD Cards
Build and Download
After configuring Recipe, build the program and download to the controller.
Execute RCP Function Block
Execute the RCP function block. Notice the Status output go from 0 (Idle) to
1 (Enable), and 2 (Succeed).
Upload Recipe Files
You can retrieve recipe files from the microSD card using a card reader or by uploading the
recipe files through the Connected Components Workbench software.
1. To use the Upload feature, go to the Properties section of your project in the Connected
Components Workbench software.
2. Select Recipe. Click Manage and then choose Upload.
Through Manage, you can also choose to Download and Delete recipe files.
3. From the Upload window that appears, select the batch of recipe files that you would
like to upload.
4. If the file already exists in your destination folder, select whether you would like to
Overwrite file, Skip file, or Preserve both Files.
