Rockwell Automation Allen-Bradley Micro830

Rockwell Automation Publication 2080-UM002N-EN-E - November 2022 49
Chapter 4 Wire Your Controller
2080-LC30-24QVB, 2080-LC50-24QVB, 2080-L50E-24QVB, DC Input Configuration
2080-LC30-48AWB, 2080-LC30-48QWB, 2080-LC50-48AWB, 2080-LC50-48QWB,
2080-LC50-48QWBK, 2080-L50E-48AWB, 2080-L50E-48QWB, 2080-L50E-48QWBK
IMPORTANT • Do not connect –DC24 (Output terminal 2) to Earth/Chassis Ground.
• In Micro870 systems that use more than four Micro800 Expansion I/O
modules, we recommend using a 1606-XLP60EQ power supply instead of
a 2080-PS120-240VAC power supply. Make sure to wire both the Micro870
controller and 2085-EP24VDC expansion power supply to the same
1606-XLP60EQ power supply.
I-00
COM0 I-01
I-02
I-03
I-04
I-05
I-06 COM1
I-07
I-09
I-08
123456789101112
+DC24 +CM0
O-00-DC24
O-01
-CM0
+CM1
O-02 O-04
O-03
O-06
O-05
123456789101112
I-11
I-10
I-13
I-12
13 14 15 16
O-08
O-07
-CM1
O-09
13 14 15 16
-24 VDC
+24 VDC
N
L
L1 L2
2080-PS120-240VAC
-DC d
CR CR
Sourcing:+DC b
Sinking: -DC b
Sourcing:-DC b
Sinking: +DC b
Sourcing:+DC a
Sinking: -DC a
Sourcing:-DC a
Sinking: +DC a
-DC e
+DC e+DC d
IMPORTANT Do not connect –DC24 (Output terminal 2) to Earth/Chassis Ground.
2080-LC30-48AWB has no high-speed inputs.
I-00
COM0 I-01
I-02
I-03
I-04
I-05
COM1
TERMINAL BLOCK 1
TERMINAL BLOCK 3
TERMINAL BLOCK 2
TERMINAL BLOCK 4
I-07
I-06
I-09
I-08
123456789101112
I-13 I-15
I-16I-14
I-17
I-18
I-19
COM3 I-21
I-20
I-23
I-22
123456789101112
I-11
I-10
I-12
COM2
13 14 15 16
I-25
I-24
I-27
I-26
13 14 15 16
-DC24
+DC24 CM0
O-00
CM1
O-01
CM2
O-02 O-03
CM3
O-04
CM4
123456789101112
CM7 O-08
O-09O-07
O-10
O-11
CM8
O-12 O-14
O-13
CM9
O-15
123456789101112
O-05
CM5
O-06
CM6
13 14 15 16
O-17
O-16
O-19
O-18
13 14 15 16
Input terminal blocks
Output terminal blocks
