Chapter 4 Wire Your Controller
IMPORTANT • Do not connect the GND pin of the serial port to Earth/Chassis Ground.
The GND pin of the serial port is the DC common for the Serial Port
Communication signals and is not intended for Shield Ground.
• If the length of the serial cable is more than 3 meters, use an isolated
serial port, catalog number 2080-SERIALISOL.
