90 Rockwell Automation Publication 2080-UM002N-EN-E - November 2022
Chapter 6 Micro870 Controller Distributed Network Protocol
22
16-bit Counter Change Object 2 - 16-bit with flag
0 - All variation
1 - 32-bit with flag
5 - 32-bit with flag and time
6 - 16-bit with flag and time
32-bit Counter Change Object 1 - 32-bit with flag
0 - All variation
2 - 16-bit with flag
5 - 32-bit with flag and time
6 - 16-bit with flag and time
23
Frozen 16-bit Counter Change Object 2 - 16-bit with flag
0 - All variation
1 - 32-bit with flag
5 - 32-bit with flag and time
6 - 16-bit with flag and time
Frozen 32-bit Counter Change Object 1 - 32-bit with flag
0 - All variation
2 - 16-bit with flag
5 - 32-bit with flag and time
6 - 16-bit with flag and time
30
16-bit Analog Input Static Object 4 - 16-bit without flag
0 - All variation
1 - 32-bit with flag
2 - 16-bit with flag
3 - 32-bit without flag
5 - Single-precision, floating-point with flag
6 - Double-precision, floating-point with flag
32-bit Analog Input Static Object 3 - 32-bit without flag
0 - All variation
1 - 32-bit with flag
2 - 16-bit with flag
4 - 16-bit without flag
5 - Single-precision, floating-point with flag
6 - Double-precision, floating-point with flag
Short Float Analog Input 5 - Single-precision, floating-point with flag
0 - All variation
1 - 32-bit with flag
2 - 16-bit with flag
3 - 32-bit without flag
4 - 16-bit without flag
6 - Double-precision, floating-point with flag
32
16-bit Analog Input Change Object 2 - 16-bit without time
0 - All variation
1 - 32-bit without time
3 - 32-bit with time
4 - 16-bit with time
5 - Single-precision, floating-point without time
6 - Double-precision, floating-point without time
7 - Single-precision, floating-point with time
8 - Double-precision, floating-point with time
32-bit Analog Input Change Object 1 - 32-bit without time
0 - All variation
2 - 16-bit without time
3 - 32-bit with time
4 - 16-bit with time
5 - Single-precision, floating-point without time
6 - Double-precision, floating-point without time
7 - Single-precision, floating-point with time
8 - Double-precision, floating-point with time
Short Float Analog Input Change Object 5 - Single-precision, floating-point without time
0 - All variation
1 - 32-bit without time
2 - 16-bit without time
3 - 32-bit with time
4 - 16-bit with time
6 - Double-precision, floating-point without time
7 - Single-precision, floating-point with time
8 - Double-precision, floating-point with time
Table 7 - DNP3 Default Variation Configuration File (Continued)
Group Default Variation for the following Objects Standard Default Variation Alternate Default Variations
