146 Rockwell Automation Publication 2711P-UM008I-EN-P - February 2022
Chapter 4
6. Click Refresh to view the change (in needed).
Web Server Configuration
The web server tab in the Network Server Configuration application
configures settings that are used for HTTP web activities. These parameters
are standard Microsoft Windows CE parameters.
Download selected files from the remote
terminal to the local terminal.
Upload selected files from the local terminal
to the remote terminal.
Indicates the current
directory level.
Double-click the arrow to move
up one directory level.
Message field that records
actions and errors for the
current VNC session.
Rename = opens a dialog box where you can rename the selected file or folder.
Mkdir = lets you create a folder.
Remove = deletes the selected file or folder.
Refresh = updates the view.
TIP Click OK in the title bar of the dialog box to apply new settings. You are
asked if you want to restart the service immediately.
