Chapter 1
Catalog Number Explanation
This section provides an explanation of the catalog numbers.
Bulletin Input Type Display Size Display Type Network Power
Operating
System
Model - Option
|| | | || | ||
2711P- T = Touch 7 = 6.5-in. C = Color 22 = Ethernet DLR ports A = AC
(Series
A only)
9 = Windows CE 6.0
(Series A and Series B for
Stainless Steel))
or
9 = Windows 10 IoT Core
(Series B and Series C for
Stainless Steel Terminals)
P =Performance - B = No brand identity
B = Key and
Touch
9 = 9-in. W = Wide
aspect ratio
color
D = DC - BSHK
(1)
= No brand
identity, stainless steel,
hygienic, conformal
coated
10 = 10.4-in. K = Conformal coated
12 = 12.1-in. BM001– BM016
(2)
=
ArmorView Plus 7
terminal
15 = 15-in.
19 = 19-in.
(1) The -BSHK terminals are available in 9-in. and 12.1-in. touch screen terminals, with DC power, and without the Allen-Bradley logo.
(2) The ArmorView Plus 7 product includes a 12.1-in. PanelView Plus 7 Performance terminal and a 1732E ArmorBlock® EtherNet/IP I/O module. Both products are enclosed in a cast aluminum assembly
that can be mounted on a machine, an arm mount system, a VESA-compatible bracket (with the optional VESA kit), or a pedestal. To order an ArmorView Plus 7 terminal, add BM001…BM016 to the
12.1-in. PanelView Plus 7 Performance touch terminal, 2711P-T12W22D9P. For explanations of the ArmorView Plus 7 catalog numbers, see the ArmorView Plus 7 Installation Instructions,
publication
2711P-IN013.
