Rockwell Automation Allen-Bradley PanelView Plus Series User Manual

Publication 2711P-UM001D-EN-P - September 2005
Install and Replace Components 5-17
For PanelView Plus 700 and 1000
Work on a clean, flat, stable surface to protect the display from
debris, scratches and damage.
6. Press the retaining tab that secures the backlight and then pull
out the backlight.
7. Insert the new backlight.
Backlight
Retaining Tab
Backlight
