Rockwell Automation Allen-Bradley PanelView Plus Series User Manual

Publication 2711P-UM001D-EN-P - September 2005
7-4 Transfer files and Upgrade Firmware
5. Select Finish to copy the firmware source files to the location
specified in step 2.
2. Upgrade Firmware in Terminal using Firmware Upgrade Card
1. Insert the compact flash card into the card slot of a powered
terminal. A dialog appears indicating the firmware upgrade is
about to occur.
2. Press Upgrade to begin the firmware upgrade.
TIP
If the files were created in a separate folder on
a local hard drive, copy the files to the root
directory of the compact flash card.
IMPORTANT
Do NOT remove the compact flash card while the
upgrade is in process.
