Troubleshooting 8-11
Startup Information
Messages
The table provides a list of system information messages that display
at startup. The messages are in the order that they appear on the
terminal screen during startup and typically display for a few seconds.
The messages apply to all terminals except where indicated.
Startup information messages show the startup sequence of the
terminal but do not require that you perform any action.
Message # Displayed Message Description
37
(2)
Video Initialized Configures and initializes the graphics video system.
30 Watchdog Test Tests the watchdog circuitry to verify system integrity.
1 RAM Test Tests the RAM memory.
31
(2)
Stuck Key Checks the integrity of the function key hardware.
31.5
(2)
Stuck Touch Checks the integrity of the touch screen hardware.
32
(2)
Battery Test Checks the integrity of the battery hardware.
2.5
(2)
Registry Search Locates and loads the most recent, valid registry. Multiple copies of the registry are
maintained. If power is lost during a registry update, a valid registry is available the next
time power is applied to the terminal.
2 Image Search Checks for new OS firmware upgrade on the external compact flash card and the serial port.
11
(1)
Downloading Image Downloads a new OS firmware upgrade to internal RAM. Message may remain on screen
for several minutes.
50
(2)
External CF Transfers a new OS firmware upgrade from the external compact flash card to the terminal.
Message may display for several minutes.
20
(1)
Transfer Image Programs the OS firmware just downloaded into RAM. Message may remain on screen for
several minutes.
23
(2)
Internal CF Programs the OS firmware just downloaded into the internal flash memory. Message may
display for several minutes.
24 CRC Check Checks the integrity of the OS firmware.
27
(1)
Decompress System Decompresses the compressed OS firmware into RAM.
28 Starting System Launches the operating system (OS).
29
(2)
System Check ### Internal file system integrity check (### is percent progress indicator).
29.1
(2)
System Check Internal file system integrity check disabled. Contact technical support.
(1)
The status number and message displays only on the 400 and 600 terminals.
(2)
The status number and message displays only on the 700-1500 terminals.
