1 Publication 2711P-UM001D-EN-P - September 2005
Appendix
A
Specifications
Electrical
Environmental
DC Power 400 and 600
Input Voltage DC
Power Consumption DC
DC Power 700 - 1500
Input Voltage DC
Power Consumption DC
24V dc nom (18…30V dc)
25 W max (1.0 A at 24V dc)
24V dc nom (18…32V dc)
70 W max (2.9 A at 24V dc)
AC Power 400 and 600
Input Voltage AC
Line Frequency
Power Consumption AC
AC Power 700 - 1500 (2711P-RSAC)
Input Voltage AC
Line Frequency
Power Consumption AC
85…264V ac
47…63 Hz
60 VA max
85…264V ac
47…63 Hz
120 VA max
Operating Temperature 0…55 °C (32…131 °F)
Storage Temperature -25…70 °C (-13 to 158 °F)
Heat Dissipation
400 and 600
700-1500
85 BTU/hr
240 BTU/hr
Relative Humidity 5…95% without condensation
Altitude Operating 2000 m (6561 ft)
Shock Operating 15 g at 11 ms
Shock Non-Operating 30 g at 11 ms
Vibration 10…57 Hz, 0.012 pk-pk displacement
57…500 Hz, 2 g pk acceleration
Enclosure Ratings NEMA Type 12, 13, 4X (Indoor use only),
IP54, IP65
