Rockwell Automation Allen-Bradley PanelView Plus Series

Publication 2711P-UM001D-EN-P - September 2005
A-2 Specifications
Display
Display Type
400 and 600 Monochrome
600 - 1500 Color
Monochrome Passive Matrix, Film
Compensated Super-Twist Nematic (FSTN)
Color Active Matrix TFT Thin-Film Transistor
with LCD Liquid Crystal Display
Display Size, Diagonal
400
600
700
1000
1250 and 1250 High-Bright
1500
3.8 in
5.5 in
6.5 in
10.4 in
12.1 in
15.0 in
Display Area (W x H)
400
600
700
1000
1250 and 1250 High-Bright
1500
78 x 59 mm (3.07 x 2.32 in)
111 x 84 mm (4.37 x 3.30 in)
132 x 99 mm (5.20 x 3.90 in)
211 x 158 mm (8.31 x 6.22 in)
246 x 184 mm (9.69 x 7.25 in)
304 x 228 mm (11.98 x 8.98)
Resolution
400
600
700
1000
1250 and 1250 High-Bright
1500
320 x 240
320 x 240
640 x 480
640 x 480
800 x 600
1024 x 768
Luminance
700-1500
1250 High-Bright
300 cd/m
2
(Nits)
1000 cd/m
2
(Nits)
Backlight
400
600 - 1500
1250 High-Bright
LED
CCFL 50,000 hours life, minimum
Backlight not replaceable
Touch Screen
Touch Technology
Actuation Rating
Operating Force
Analog resistive
1 million presses
10…110 g
Keypad
Function Keys
(1)
Actuation Rating
Operating Force
(1)
number of function keys varies by terminal size
Function keys, numeric and navigation
1 million presses
340 g
