Rockwell Automation Allen-Bradley PanelView Plus Series

Publication 2711P-UM001D-EN-P - September 2005
Specifications A-3
Mechanical
General
Weight (for base unit without modules)
400 Keypad
(1)
600 Keypad or Keypad & Touch
(1)
600 Touch
(1)
700 Keypad or Keypad & Touch
700 Touch
1000 Keypad or Keypad & Touch
1000 Touch
1250 Keypad or Keypad & Touch
1250 Touch and 1250 High-Bright Touch
1500 Keypad or Keypad & Touch
1500 Touch
(1)
Add approximately 95 g (0.21 lb) for communication module
562 g (1.24 lb)
930 g (2.05 lb)
789 g (1.74 lb)
1.9 kg (4.2 lb)
1.7 kg (3.8 lb)
2.9 kg (6.3 lb)
2.6 kg (5.7 lb)
3.4 kg (7.6 lb)
3.2 kg (7.1 lb)
4.6 kg (10.0 lb)
4.2 kg (9.3 lb)
Dimensions H x W x D (for base unit without communication module)
400 Keypad 152 x 185 x 90 mm (6.0 x 7.28 x 3.54 in)
600 Keypad or Keypad & Touch 167 x 266 x 98 mm (6.58 x 10.47 x 3.86 in)
600 Touch 152 x 185 x 98 mm (6.0 x 7.28 x 3.86 in)
700 Keypad or Keypad & Touch 193 x 290 x 55 mm (7.58 x 11.40 x 2.18 in)
700 Touch 179 x 246 x 55 mm (7.04 x 9.68 x 2.18 in)
1000 Keypad or Keypad & Touch 248 x 399 x 55 mm (9.77 x 15.72 x 2.18 in)
1000 Touch 248 x 329 x 55 mm (9.77 x 12.97 x 2.18 in)
1250 Keypad or Keypad & Touch 282 x 416 x 55 mm (11.12 x 16.36 x 2.18 in)
1250 Touch 282 x 363 x 55 mm (11.12 x 14.30 x 2.18 in)
1250 Touch High Bright 282 x 363 x 74 mm (11.12 x 14.30 x 2.90 in)
1500 Keypad or Keypad & Touch 330 x 469 x 65 mm (12.97 x 18.46 x 2.55 in)
1500 Touch 330 x 416 x 65 mm (12.97 x 16.37 x 2.55 in)
Battery Life
400 and 600
700-1500
5 years minimum at 25 °C
4 years minimum at 25 °C
Clock Battery-backed, +/-2 minutes per month
LED Indicators COMM (Green), Fault (Red)
Application Flash Memory
400 and 600
700-1500
5 MB
12 MB
External Compact Flash Storage 512 MB maximum
