Appendix C
Renewal Parts
One piece provided per part number.
5…85 A power pole structure does not include heatsink fan.
Three-phase power pole structure provided per part no.
One-phase power pole provided per part no.
Description SMC Rating Input Control Voltage
Part No.
Control Modules Standard All 120…240V AC 41391-454-01-S1FX
Pump Control All 41391-454-01-B1FX
Braking Control 5…85 A 41391-454-01-D1AX
108…251 A 41391-454-01-D1BX
317…480 A 41391-454-01-D1CX
Standard All 24V AC/DC 41391-454-02-S2FX
Pump Control All 41391-454-02-B2FX
Braking Control 5…85 A 41391-454-02-D2AX
108…251 A 41391-454-02-D2BX
317…480 A 41391-454-02-D2CX
Description SMC Rating Line Voltage
Part No.
Power Poles 5 A 200…480V 150-FPP5B ➁➂
25 A 200…480V 150-FPP25B ➁➂
43 A 200…480V 150-FPP43B ➁➂
60 A 200…480V 150-FPP60B ➁➂
85 A 200…480V 150-FPP85B ➁➂
108 A 200…480V 41391-800-01
135 A 200…480V 41391-800-03
201 A 200…480V 41391-800-05
251 A 200…480V 41391-800-07
317 A 200…480V 41391-800-09
361 A 200…480V 41391-800-11
480 A 200…480V 41391-800-13
5 A 200…600V 150-FPP5C ➁➂
25 A 200…600V 150-FPP25C ➁➂
43 A 200…600V 150-FPP43C ➁➂
60 A 200…600V 150-FPP60C ➁➂
85 A 200…600V 150-FPP85C ➁➂
108 A 200…600V 41391-800-02
135 A 200…600V 41391-800-04
201 A 200…600V 41391-800-06
251 A 200…600V 41391-800-08
317 A 200…600V 41391-800-10
361 A 200…600V 41391-800-12
480 A 200…600V 41391-800-14
Heatsink Fans 5…85 A All 41391-801-03
108…251 A All 41391-801-01
317…480 A All 41391-801-02
Base Plate 108…251 A All 41391-803-01
317…480 A All 41391-803-02
