Installation 2-5
Figure 2.1 Dimensions: 5…85 A Controllers
All dimensions are approximate and are not intended for manufacturing purposes. Consult your
local Allen-Bradley distributor for complete dimension drawings.
Unit
A
Width
B
Height
C
Depth
DEFH
Approx.
Ship. Wt.
5…85 A
Controller
mm 150.1 307 203.1 120 291 119.8 14.1 5.7 kg
in. 5.91 12.09 8.00 4.72 11.46 4.72 0.56 12.6 lb.
C
F
B
E
A
D
H
