Programming and Parameters Chapter 3
Fault and Diagnostic Group (continued)
F701 [EN Gateway Act 1]
F702 [EN Gateway Act 2]
F703 [EN Gateway Act 3]
F704 [EN Gateway Act 4]
PowerFlex 525 only.
Shows the actual gateway address used by the embedded EtherNet/IP interface at the time. This will indicate 0 if no address is set.
Values Default: Read Only
Min/Max: 0/255
Display: 1
PF 525
255.255.255.255
[EN Gateway Act 1]
[EN Gateway Act 2]
[EN Gateway Act 3]
[EN Gateway Act 4]
F705 [Drv 0 Logic Cmd]
F709 [Drv 1 Logic Cmd]
F713 [Drv 2 Logic Cmd]
F717 [Drv 3 Logic Cmd]
F721 [Drv 4 Logic Cmd]
In multi-drive mode, this is the logic command being transmitted to drive 0/1/2/3/4/.
In single-drive mode, this is the logic command being used by the drive (whether HS-DSI, EtherNet/IP, or DSI) at the time. If comms control is NOT being used, and the drive is in single-
drive mode, then this parameter will show 0.
Values Default: Read Only
Min/Max: 0/FFFF
Display: 1
F706 [Drv 0 Reference]
F710 [Drv 1 Reference]
F714 [Drv 2 Reference]
F718 [Drv 3 Reference]
F722 [Drv 4 Reference]
In multi-drive mode, this is the reference being transmitted to drive 0/1/2/3/4.
In single-drive mode, this is the reference being used by the drive (whether HS-DSI, EtherNet/IP, or DSI) at the time. If comms control is NOT being used, and the drive is in single-drive
mode, then this parameter will show 0.
Values Default: Read Only
Min/Max: 0.00/500.00 Hz
Display: 0.01 Hz
F707 [Drv 0 Logic Sts]
F711 [Drv 1 Logic Sts]
F715 [Drv 2 Logic Sts]
F719 [Drv 3 Logic Sts]
F723 [Drv 4 Logic Sts]
In multi-drive mode, this is the logic status being received from drive 0/1/2/3/4.
In single-drive mode, this is the logic status of the drive at the time.
Values Default: Read Only
Min/Max: 0/FFFF
Display: 1
