1-10 PowerFlex 40 Standard Configured Drive Standard Features and Options
Publication 23B-IN001G
Auto/Manual Selector Switch (Position 16+, Code S4)
This 800F door mounted operator device is factory installed and provides an
Auto/Manual selector switch.
The Auto/Manual selector switch determines the source of the actual drive
speed reference. Using 2-wire control in Auto mode, speed source is
parameter A071 [Preset Freq 1]. In Manual mode, the speed source is
parameter A072 [Preset Freq 2].
If the door mounted speed potentiometer (Option S18) is supplied and it is
intended to be the speed reference in Manual mode, set parameter P052
[Digital In2 Sel] to option 13 “10V In Ctrl”. Refer to the table below and the
PowerFlex 40 User Manual, publication 22B-UM001, for other options.
Auto/Manual Selector Switch (Code S4)
Component Specifications
This option is not compatible with Codes R3, R5, S1, S20, S21 or S22.
Speed Reference Parameter Settings
Manual Mode Auto Mode P038 [Speed Reference] A051 [Digital In1 Sel] A052 [Digital In2 Sel]
Preset Speed Preset Speed 4 “Preset Freq” 4 “Preset Freq” 4 “Preset Freq”
Analog Input (0-10V) 4 “Preset Freq” 13 “10V In Ctrl” 4 “Preset Freq”
Analog Input (4-20mA) 4 “Preset Freq” 14 “20mA In Ctrl” 4 “Preset Freq”
Communication Port
(1)
4 “Preset Freq” 6 “Comm Port” 4 “Preset Freq”
Speed Pot (Door) Preset Speed 4 “Preset Freq” 4 “Preset Freq” 13 “10V In Ctrl”
Analog Input (4-20mA) 4 “Preset Freq” 14 “20mA In Ctrl” 13 “10V In Ctrl”
Communication Port
(1)
4 “Preset Freq” 6 “Comm Port” 13 “10V In Ctrl”
HIM (Door) Preset Speed 4 “Preset Freq” 4 “Preset Freq” 6 “Comm Port”
Analog Input (0-10V) 4 “Preset Freq” 13 “10V In Ctrl” 6 “Comm Port”
Analog Input (4-20mA) 4 “Preset Freq” 14 “20mA In Ctrl” 6 “Comm Port”
(1)
Communication port will have both logic and reference control.
Bulletin 800F
Devices
IEC style, Internationally rated
Meet IP65/IP66 and NEMA/UL Type 4/4X/13
UL Listed, CSA Certified
10 amp contacts
Screw terminals, 0.3–3.5 mm
2
(22–12 AWG) maximum
Auto/Manual
Selector Switch
2 position, Maintained
1 N.C. contact
Legend Plate 30 x 50 mm, Black with white lettering
Wiring 0.8 mm
2
(18 AWG), Blue
Schematics Figure 2.6 on page 2-7
Figure 2.7 on page 2-8
Figure 2.8 on page 2-9
