PowerFlex 40 Standard Configured Drive Standard Features and Options 1-11
Publication 23B-IN001G
Start and Stop Push Buttons (Position 16+, Code S7)
This option provides factory installed 800F Start and Stop push buttons.
In all cases, the Stop input to the drive must be present before the drive will
start. Using 3-wire control, speed source is parameter A070 [Preset Freq 0].
The Stop push button may also be used as a fault reset.
Component Specifications
This option is not compatible with Codes R3, R5, S1, S20, S21, S22 or S23.
Forward/Reverse Selector Switch (Position 16+, Code S8)
This 800F door mounted operator device is factory installed and provides a
Forward/Reverse selector switch.
When configured for 2-wire control, the drive will start when the selector
switch is set to Forward. When the selector switch is set to Reverse, the
drive will run in reverse. If the selector switch is operated while the drive is
running, a change of direction command will occur. If the drive is stopped
and the selector switch is operated, a change of direction command will
occur. The speed source is parameter P070 [Preset Freq 0].
When configured for 3-wire control (Code S7 with S8), the selector switch
only changes direction. The drive is started and stopped via the Start and
Stop push buttons (Code S7).
Component Specifications
This option is not compatible with Codes R3, R5, S20 or S21.
Bulletin 800F
Devices
IEC style, Internationally rated
Meet IP65/IP66 and NEMA/UL Type 4/4X/13
UL Listed, CSA Certified
10 amp contacts
Screw terminals, 0.3–3.5 mm
2
(22–12 AWG) maximum
Start Push Button Flush head, Green, 1 N.O. contact
Stop Push Button Extended head, Red, 1 N.C. contact
Legend Plate 30 x 50 mm, Black with white lettering
Wiring 0.8 mm
2
(18 AWG), Blue
Schematics Figure 2.7 on page 2-8
Figure 2.9 on page 2-10
Figure 2.10 on page 2-11
Bulletin 800F
Devices
IEC style, Internationally rated
Meet IP65/IP66 and NEMA/UL Type 4/4X/13
UL Listed, CSA Certified
10 amp contacts
Screw terminals, 0.3–3.5 mm
2
(22–12 AWG) maximum
Forward/Reverse
Selector Switch
2-Wire: 2 position, Maintained, 1 N.O. & 1 N.C. contacts
3-Wire: 2 position, Maintained, 1 N.C. contact
Legend Plate 30 x 50 mm, Black with white lettering
Wiring 0.8 mm
2
(18 AWG), Blue
Schematics 2-Wire Control: Figure 2.5 on page 2-6
, Figure 2.8 on page 2-9,
Figure 2.11 on page 2-12
3-Wire Control: Figure 2.10 on page 2-11
