Rockwell Automation PowerFlex 40 Installation Instructions

1-12 PowerFlex 40 Standard Configured Drive Standard Features and Options
Publication 23B-IN001G
Local Speed Potentiometer (Code S18)
This option provides a factory installed 800F door mounted one turn
potentiometer for speed control. The device provides the speed source when
no digital inputs are active.
When this option is provided, it becomes the speed source for the Hand
mode of the Hand/Off/Auto selector switch (Option S1) and the Manual
mode of the Auto/Manual selector switch (Option S4).
Component Specifications
This option is not compatible with Codes R3-R5.
Local Control Off/Run Forward and Local/Remote Selector Switches
(Code S20)
This option provides two factory installed 800F door mounted selector
switches. The Local/Remote selector switch determines the source of the
start, stop, speed and direction commands. In Local mode, the factory
default setting for parameter P038 [Speed Reference] = 4 “Preset Freq.”
In Remote mode, the factory default setting for parameter A051 [Digital In1
Sel] = 6 “Comm Port.” The Off/Run Forward selector switch allows the
drive to be started and stopped when in Local Control.
Component Specifications
This option is not compatible with Codes R3, R5, S1, S4, S7, S8, S21 or
S22.
Bulletin 800F
Devices
IEC style, Internationally rated
Meet IP65/IP66 and NEMA/UL Type 4/4X/13
UL Listed, CSA Certified
Screw terminals, 0.3–3.5 mm
2
(22–12 AWG) maximum
Speed Potentiometer 1-turn, 10k, 2.25W, 500V
Legend Plate 30 x 50 mm, Black with white lettering
Wiring 0.8 mm
2
(18 AWG), Blue
Schematic Figure 2.13 on page 2-14
Bulletin 800F Devices IEC style, Internationally rated
Meet IP65/IP66 and NEMA/UL Type 4/4X/13
UL Listed, CSA Certified
10 amp contacts
Screw terminals, 0.3–3.5 mm
2
(22–12 AWG) maximum
Local Control Off/Run
Forward Selector Switch
2 position, Maintained, 1 N.O. contact
Local/Remote
Selector Switch
2 position, Maintained, 1 N.O. contact
Legend Plate 30 x 50 mm, Black with white lettering
Wiring 0.8 mm
2
(18 AWG), Blue
Schematic Figure 2.12 on page 2-13
