Rockwell PowerFlex 70 User Manual

Chapter 3
Programming and Parameters
Chapter 3 provides a complete listing and description of the
PowerFlex 70 parameters. The parameters can be programmed (viewed/
edited) using an LED or LCD HIM (Human Interface Module).
As an alternative, programming can also be performed using
DriveExplorer™ or DriveExecutive™ software and a personal computer.
Refer to Appendix
B for brief descriptions of the LED and LCD Human
Interface Modules.
To configure a drive to operate in a specific way, drive parameters may
have to be set. Three types of parameters exist:
• ENUM Parameters
ENUM parameters allow a selection from 2 or more items. The LCD
HIM will display a text message for each item. The LED HIM will
display a number for each item.
• Bit Parameters
Bit parameters have individual bits associated with features or
conditions. If the bit is 0, the feature is off or the condition is false. If
the bit is 1, the feature is on or the condition is true.
• Numeric Parameters
These parameters have a single numerical value (i.e. 0.1 Volts).
The example on the following page shows how each parameter type is
presented in this manual.
For information on… See page…
About Parameters
3-1
How Parameters are Organized 3-3
Monitor File (File A) 3-11
Motor Control File (File B) 3-13
Speed Command File (File C) 3-20
Dynamic Control File (File D) 3-29
Utility File (File E) 3-36
Communication File (File H) 3-47
Inputs & Outputs File (File J) 3-52
Applications File (File K) 3-59
Parameter Cross Reference – by Name 3-60
About Parameters

Rockwell PowerFlex 70 Specifications
