Overview P-5
Catalog Number Explanation
a
Drive
Code Type
20A PowerFlex 70
b
Voltage Rating
Code Voltage Ph.
B 240V ac 3
C 400V ac 3
D 480V ac 3
E 600V ac 3
c3
ND Rating
400V, 50 Hz Input
Code Amps kW (Hp)
1P3 1.3 0.37 (0.5)
2P1 2.1 0.75 (1.0)
3P5 3.5 1.5 (2.0)
5P0 5.0 2.2 (3.0)
8P7 8.7 4.0 (5.0)
011 11.5 5.5 (7.5)
015 15.4 7.5 (10)
022 22 11 (15)
030 30 15 (20)
037 37 18.5 (25)
043 43 22 (30)
060 60 30 (40)
072 72 37 (50)
c4
ND Rating
480V, 60 Hz Input
Code Amps kW (Hp)
1P1 1.1 0.37 (0.5)
2P1 2.1 0.75 (1.0)
3P4 3.4 1.5 (2.0)
5P0 5.0 2.2 (3.0)
8P0 8.0 3.7 (5.0)
011 11 5.5 (7.5)
014 14 7.5 (10)
022 22 11 (15)
027 27 15 (20)
034 34 18.5 (25)
040 40 22 (30)
052 52 30 (40)
065 65 37 (50)
d
Enclosure
Code Enclosure
A
Panel Mount - IP 20, NEMA
Type 1
C
Wall/Machine Mount = IP66,
NEMA Type 4X/12 for indoor
use only
F
Flange Mount - Front Chassis
=
IP 20, NEMA Type 1; Rear
Heatsink = IP66, UL Type 4X/1
2
for indoor/outdoor use
G
Wall/Machine Mount - IP54,
NEMA Type 12
c1
ND Rating
208V, 60 Hz Input
Code Amps kW (Hp)
2P2 2.5 0.37 (0.5)
4P2 4.8 0.75 (1.0)
6P8 7.8 1.5 (2.0)
9P6 11 2.2 (3.0)
015 17.5 4.0 (5.0)
022 25.3 5.5 (7.5)
028 32.2 7.5 (10)
042 43 11 (15)
054 62.1 15 (20)
070 78.2 18.5 (25)
c2
ND Rating
240V, 60 Hz Input
Code Amps kW (Hp)
2P2 2.2 0.37 (0.5)
4P2 4.2 0.75 (1.0)
6P8 6.8 1.5 (2.0)
9P6 9.6 2.2 (3.0)
015 15.3 4.0 (5.0)
022 22 5.5 (7.5)
028 28 7.5 (10)
042 42 11 (15)
054 54 15 (20)
070 70 18.5 (25)
c5
ND Rating
600V, 60 Hz Input
Code Amps kW (Hp)
0P9 0.9 0.37 (0.5)
1P7 1.7 0.75 (1.0)
2P7 2.7 1.5 (2.0)
3P9 3.9 2.2 (3.0)
6P1 6.1 4.0 (5.0)
9P0 9.0 5.5 (7.5)
011 11 7.5 (10)
017 17 11 (15)
022 22 15 (20)
027 27 18.5 (25)
032 32 22 (30)
041 41 30 (40)
052 52 37 (50)
e
HIM !
Code Interface Module
0 Blank Cover
2 Digital LCD
3 Full Numeric LCD
5 Prog. Only LCD
8 !
Wireless Interface Module
! IP66, NEMA Type 4X/12 (Enclosure Code C) i
s
available only with HIM Codes 0, 3, 5, or 8.
! HIM Code 8 is available only with IP66, NEM
A
Type 4X/12 enclosures.
Position Number
1-3 45-78 9 101112131415 16
20A B 2P2 A 3 A Y Y N N C 0
abcdefghi jkl
