Rockwell PowerFlex 70 User Manual

Programming and Parameters 3-11
Monitor File (File A)
File A Group No.
Parameter Name and Description
See page 3-2 for symbol descriptions
Values
Related
MONITOR (File A)
Metering
001 [Output Freq]
Output frequency present at T1, T2 & T3
(U, V & W)
Default:
Min/Max:
Units:
Read Only
–/+[Maximum Freq]
0.1 Hz
002 [Commanded Freq]
Value of the active frequency command.
Default:
Min/Max:
Units:
Read Only
–/+[Maximum Speed]
0.1 Hz
003 [Output Current]
The total output current present at T1, T2
& T3 (U, V & W).
Default:
Min/Max:
Units:
Read Only
0.0/Drive Rated Amps × 2
0.1 Amps
0.01 Amps
004 [Torque Current]
The amount of current that is in phase
with the fundamental voltage component.
Default:
Min/Max:
Units:
Read Only
Drive Rating × –2/+2
0.1 Amps
0.01 Amps
005 [Flux Current]
The amount of current that is out of phase
with the fundamental voltage component.
Default:
Min/Max:
Units:
Read Only
Drive Rating × –2/+2
0.1 Amps
0.01 Amps
006 [Output Voltage]
Output voltage present at terminals T1,
T2 & T3 (U, V & W).
Default:
Min/Max:
Units:
Read Only
0.0/Drive Rated Volts
0.1 VAC
007 [Output Power]
Output power present at T1, T2 & T3 (U, V
& W).
Default:
Min/Max:
Units:
Read Only
0.0/Drive Rated kW × 2
0.1 kW
0.01 kW
008 [Output Powr Fctr]
Output power factor.
Default:
Min/Max:
Units:
Read Only
0.00/1.00
0.01
009 [Elapsed MWh]
Accumulated output energy of the drive.
Default:
Min/Max:
Units:
Read Only
0.0/429496729.5 MWh
0.1 MWh
010 [Elapsed Run Time]
Accumulated time drive is outputting
power.
Default:
Min/Max:
Units:
Read Only
0.0/429496729.5 Hrs
0.1 Hrs
011 [MOP Frequency]
Value of the signal at MOP (Motor
Operated Potentiometer).
Default:
Min/Max:
Units:
Read Only
–/+[Maximum Frequency]
0.1 Hz
012 [DC Bus Voltage]
Present DC bus voltage level.
Default:
Min/Max:
Units:
Read Only
0.0/Drive Rating Based
0.1 VDC
013 [DC Bus Memory]
6 minute average of DC bus voltage level.
Default:
Min/Max:
Units:
Read Only
0.0/Drive Rating Based
0.1 VDC
32
E C
E C
32
E C
E C
32
E C
E C
32
E C
E C
32
32
