Rockwell PowerFlex 70 User Manual

3-12 Programming and Parameters
MONITOR (File A)
Metering
014 [Elapsed kWh]
Accumulated output energy of the drive.
Default:
Min/Max:
Units:
Read Only
0.0/429496729.5 kWh
0.1 kWh
015 [Torque Estimate]
Estimated motor torque output as percent
of motor rated torque.
Default:
Min/Max:
Units:
Read Only
–/+800.0 %
0.1 %
016
017
[Analog In1 Value]
[Analog In2 Value]
Value of the signal at the analog inputs.
Default:
Min/Max:
Units:
Read Only
0.000/20.000 mA
–/+10.000V
0.001 mA
0.001 Volt
022 [Ramped Speed]
The value shown is the value after the
accel/decel ramp but prior to any
corrections supplied by slip comp, PI, etc.
Default:
Min/Max:
Units:
Read Only
–/+500.0 Hz
0.1 Hz
023 [Speed Reference]
Summed value of ramped speed and
Process PI.
Default:
Min/Max:
Units:
Read Only
–/+500.0 Hz
0.1 Hz
024 [Commanded Torque]
Final torque reference value after limits &
filtering are applied. % motor rated torque.
Default:
Min/Max:
Units:
Read Only
–/+800.0%
0.1%
053
025 [Speed Feedback]
Value of actual motor speed, measured by
encoder feedback or estimated.
Default:
Min/Max:
Units:
Read Only
–/+500.0 Hz
0.1 Hz
053
Drive Data
026 [Rated kW]
Drive power rating.
Default:
Min/Max:
Units:
Read Only
0.37/15.0 kW
0.00/300.00 kW
0.01 kW
027 [Rated Volts]
The drive input voltage class (208, 240,
400 etc.).
Default:
Min/Max:
Units:
Read Only
208/600 Volt
0.0/6553.5 Volt
0.1 VAC
028 [Rated Amps]
The drive rated output current.
Default:
Min/Max:
Units:
Read Only
1.1/32.2 Amps
0.0/6553.5 Amps
0.1 Amps
029 [Control SW Ver]
Main Control Board software version.
Default:
Min/Max:
Units:
Read Only
0.000/65.256
0.0/65.535
0.001
196
File A Group No.
Parameter Name and Description
See page 3-2 for symbol descriptions
Values
Related
32
E C
E C v3
E C
E C
FV
E C v2
E C v2
32
E C
E C
E C
E C
