Programming and Parameters 3-37
UTILITY (File E)
MOP Config
194 [Save MOP Ref]
Enables/disables the feature that saves the present MOP frequency reference at
power down or at stop.
195 [MOP Rate]
Sets rate of change of the MOP reference
in response to a digital input.
Default:
Min/Max:
Units:
1.0 Hz/s
0.2/[Maximum Freq]
0.1 Hz/s
Drive Memory
196 [Param Access Lvl]
Selects the parameter display level.
Basic = Reduced param. set
Advanced = Full param. set
Default:
Options:
0
0
1
2
“Basic”
“Basic”
“Advanced”
“Reserved”
197 [Reset To Defalts]
Resets all parameter values (except
parameters 196, 201 & 202) to defaults.
Option 1 resets drive to factory settings.
Options 2 and 3 will reset drive to
alternate voltage and current rating.
Default:
Options:
0
0
1
2
3
“Ready”
“Ready”
“Factory”
“Low Voltage”
“High Voltage”
198 [Load Frm Usr Set]
Loads a previously saved set of
parameter values from a selected user set
location in drive nonvolatile memory to
active drive memory.
Default:
Options:
0
0
1
2
3
“Ready”
“Ready”
“User Set 1”
“User Set 2”
“User Set 3”
199
199 [Save To User Set]
Saves the parameter values in active drive
memory to a user set in drive nonvolatile
memory.
Default:
Options:
0
0
1
2
3
“Ready”
“Ready”
“User Set 1”
“User Set 2”
“User Set 3”
198
200 [Reset Meters]
Resets selected meters to zero.
Default:
Options:
0
0
1
2
“Ready”
“Ready”
“MWh”
“Elapsed Time”
201 [Language]
Selects the display language when using
an LCD HIM. This parameter is not
functional with an LED HIM.
Default:
Options:
0
0
1
2
3
4
5
6
7
8-9
10
“Not Selected”
“Not Selected”
“English”
“Français”
“Español”
“Italiano”
“Deutsch”
“Reserved”
“Português”
“Reserved”
“Nederlands”
File E
Group
No.
Parameter Name and Description
See page 3-2 for symbol descriptions
Values
Related
0xx 0xxxxxxxxxxxx
10 01234567891112131415
1 = Save
0 = Do Not Save
x = Reserved
Bit #
Factory Default Bit Values
At Powr Down
At Stop
Nibble 1Nibble 2Nibble 3Nibble 4
E C
