Rockwell PowerFlex 70 User Manual

3-60 Programming and Parameters
Parameter Cross Reference – by Name
Parameter Name Number Group Page
Accel Mask 281 Masks & Owners 3-48
Accel Owner 293 Masks & Owners 3-49
Accel Time X 140, 141 Ramp Rates 3-29
Alarm Config 1 259 Alarms 3-46
Alarm X @ Fault 229, 230 Diagnostics 3-43
Analog In X Hi 322, 325 Analog Inputs 3-52
Analog In X Lo 323, 326 Analog Inputs 3-52
Analog In X Loss 324, 327 Analog Inputs 3-52
Analog In1 Value 16 Metering 3-12
Analog In2 Value 17 Metering 3-12
Analog Out1 Hi 343 Analog Outputs 3-54
Analog Out1 Lo 344 Analog Outputs 3-54
Analog Out1 Sel 342 Analog Outputs 3-53
Anlg In Config 320 Analog Inputs 3-52
Anlg In Sqr Root 321 Analog Inputs 3-52
Anlg Out Absolut 341 Analog Outputs 3-53
Anlg Out Config 340 Analog Outputs 3-53
Anlg Out1 Scale 354 Analog Outputs 3-54
Anlg Out1 Setpt 377 Analog Outputs 3-54
Auto Rstrt Delay 175 Restart Modes 3-33
Auto Rstrt Tries 174 Restart Modes 3-33
AutoMan Cnfg 192 HIM Ref Config 3-36
Autotune 61 Torq Attributes 3-16
Autotune Torque 66 Torq Attributes 3-16
Break Frequency 72 Volts per Hertz 3-18
Break Voltage 71 Volts per Hertz 3-18
Bus Reg Gain 160 Stop/Brake Modes 3-31
Bus Reg Kd 165 Stop/Brake Modes 3-32
Bus Reg Ki 160 Stop/Brake Modes 3-31
Bus Reg Kp 164 Stop/Brake Modes 3-32
Bus Reg Mode X 161, 162 Stop/Brake Modes 3-31
Commanded Freq 2 Metering 3-11
Commanded Torque 24 Metering 3-12
Compensation 56 Torq Attributes 3-15
Control Status 440 Torq Attributes 3-18
Control SW Ver 29 Drive Data 3-12
Current Lmt Gain 149 Load Limits 3-29
Current Lmt Sel 147 Load Limits 3-29
Current Lmt Val 148 Load Limits 3-29
Current Rate Limit 154 Load Limits 3-30
Data In XX 300-307 Datalinks 3-50
Data Out XX 310-317 Datalinks 3-50
DB Resistor Type 163 Stop/Brake Modes 3-32
DB While Stopped 145 Stop/Brake Modes 3-30
DC Brake Level 158 Stop/Brake Modes 3-31
DC Brake Lvl Sel 157 Stop/Brake Modes 3-30
DC Brake Time 159 Stop/Brake Modes 3-31
DC Bus Memory 13 Metering 3-11
DC Bus Voltage 12 Metering 3-11
Decel Mask 282 Masks & Owners 3-48
Decel Owner 294 Masks & Owners 3-49
Decel Time X 142, 143 Ramp Rates 3-29
Dig In Status 216 Diagnostics 3-41
Dig Out Setpt 379 Digital Outputs 3-56
Dig Out Status 217 Diagnostics 3-41
Dig OutX Level 381, 385 Digital Outputs 3-57
Dig OutX OffTime 383, 387 Digital Outputs 3-58
Dig OutX OnTime 382, 386 Digital Outputs 3-57
DigIn DataLogic 411 Digital Inputs 3-56
Digital InX Sel 361-366 Digital Inputs 3-55
Digital OutX Sel 380, 384 Digital Outputs 3-57
Direction Mask 279 Masks & Owners 3-48
Direction Mode 190 Direction Config 3-36
Direction Owner 291 Masks & Owners 3-49
DPI Data Rate 270 Comm Control 3-47
DPI Port Select 274 Comm Control 3-48
DPI Port Value 275 Comm Control 3-48
DPI Ref Select 298 Comm Control 3-48
Drive Alarm X 211, 212 Diagnostics 3-39
Drive Checksum 203 Drive Memory 3-38
Drive Logic Rslt 271 Comm Control 3-47
Drive OL Count 219 Diagnostics 3-42
Drive OL Mode 150 Load Limits 3-29
Drive Ramp Rslt 273 Comm Control 3-47
Drive Ref Rslt 272 Comm Control 3-47
Drive Status 1, 2 209, 210 Diagnostics 3-39
Drive Status 3 222 Diagnostics 3-42
Drive Temp 218 Diagnostics 3-41
Droop RPM @ FLA 152 Stop/Brake Modes 3-30
Dyn UserSet Actv 206 Drive Memory 3-38
Dyn UsrSet Cnfg 204 Drive memory 3-38
Dyn UsrSet Sel 205 Drive memory 3-38
Elapsed kWh 14 Metering 3-12
Elapsed MWh 9 Metering 3-11
Elapsed Run Time 10 Metering 3-11
Enc Position Fdbk 414 Speed Feedback 3-19
Encoder PPR 413 Speed Feedback 3-19
Encoder Speed 415 Speed Feedback 3-19
Fault Amps 225 Diagnostics 3-43
Fault Bus Volts 226 Diagnostics 3-43
Fault Clear 240 Faults 3-44
Fault Clear Mode 241 Faults 3-45
Fault Clr Mask 283 Masks & Owners 3-48
Fault Clr Owner 295 Masks & Owners 3-49
Fault Config 1 238 Faults 3-44
Fault Frequency 224 Diagnostics 3-43
Fault X Code 243-249 Faults 3-45
Fault X Time 244-250 Faults 3-45
Fdbk Filter Sel 416 Speed Feedback 3-19
Feedback Select 80 Spd Mode & Limits 3-20
Fiber Control 620 Fiber Functions 3-59
Fiber Status 621 Fiber Functions 3-59
Flux Braking 166 Stop/Brake Modes 3-32
Flux Current 5 Metering 3-11
Flux Current Ref 63 Torq Attributes 3-16
Flux Up Mode 57 Torq Attributes 3-15
Flux Up Time 58 Torq Attributes 3-15
Flying Start En 169 Restart Modes 3-33
