Rockwell PowerFlex 70 User Manual

Programming and Parameters 3-43
UTILITY (File E)
Diagnostics
224 [Fault Frequency]
Captures and displays the output speed of
the drive at the time of the last fault.
Default:
Min/Max:
Units:
Read Only
0.0/+[Maximum Freq]
0.1 Hz
225
thru
230
225 [Fault Amps]
Captures and displays motor amps at the
time of the last fault.
Default:
Min/Max:
Units:
Read Only
0.0/[Rated Amps] × 2
0.1 Amps
224
thru
230
226 [Fault Bus Volts]
Captures and displays the DC bus voltage
of the drive at the time of the last fault.
Default:
Min/Max:
Units:
Read Only
0.0/Max Bus Volts
0.1 VDC
224
thru
230
227 [Status 1 @ Fault]
Captures and displays [Drive Status 1] bit pattern at
the time of the last fault.
Read Only 209
224
thru
230
228 [Status 2 @ Fault]
Captures and displays [Drive Status 2] bit pattern at
the time of the last fault.
Read Only 210
224
thru
230
229 [Alarm 1 @ Fault]
Captures and displays [Drive Alarm 1] at the time of
the last fault.
Read Only 211
224
thru
230
File E Group No.
Parameter Name and Description
See page 3-2 for symbol descriptions
Values
Related
0110000101110000
10 01234567891112131415
1 = Condition True
0 = Condition False
x = Reserved
Bit #
Ready
Active
Command Dir
Actual Dir
Accelerating
Decelerating
Alarm
Faulted
At Speed
Local ID 0
Local ID 1
Local ID 2
Spd Ref ID 0
Spd Ref ID 1
Spd Ref ID 2
Spd Ref ID 3
Nibble 1Nibble 2Nibble 3Nibble 4
00000000000000xx
10 01234567891112131415
1 = Condition True
0 = Condition False
x = Reserved
Bit #
Ready
Active
Running
Jogging
Stopping
DC Braking
AutoTuning
DB Active *
AutoRst Ctdn
AutoRst Act
Curr Limit
Bus Freq Reg
Motor Overld
DPI at 500 k
Nibble 1Nibble 2Nibble 3Nibble 4
* Enhanced Control Option Only.
000000x00000000x
10 01234567891112131415
1 =Condition True
0 =Condition False
x =Reserved
Bit #
Prechrg Actv
UnderVoltage
Power Loss
Str At PwrUp
Anlg in Loss
IntDBRes OH
Drv OL Lvl 1
Drv OL LVl 2
Decel Inhibt
Waking
(2)
Motor Therm
(1)
In PhaseLoss
(2)
Load Loss
(2)
Ground Warn
(2)
Nibble 1Nibble 2Nibble 3Nibble 4
(1)
Enhanced firmware 1.001 & later.
(2)
Enhanced firmware 2.001 & later.
