Chapter 1
Installation/Wiring
This chapter provides information on mounting and wiring the
PowerFlex 70 Drive.
Most start-up difficulties are the result of incorrect wiring. Every
precaution must be taken to assure that the wiring is done as instructed.
All items must be read and understood before the actual installation
begins.
IP 20 (NEMA Type 1)
For information on… See page For information on… See page
Opening the Cover
1-1 Disconnecting MOVs and
Common Mode Capacitors
1-11
Mounting Considerations 1-2
AC Supply Source Considerations 1-3 I/O Wiring 1-12
General Grounding Requirements 1-4 Speed Reference Control 1-19
Fuses and Circuit Breakers 1-5 Auto/Manual Examples 1-20
Power Wiring 1-5 EMC Instructions 1-21
Using Input/Output Contactors 1-10
!
ATTENTION: The following information is merely a guide for proper
installation. Rockwell Automation, Inc. cannot assume responsibility
for the compliance or the noncompliance to any code, national, local or
otherwise for the proper installation of this drive or associated
equipment. A hazard of personal injury and/or equipment damage
exists if codes are ignored during installation.
Opening the Cover
1. Loosen cover screw. 2. Pull cover straight off chassis to
avoid damaging connector pins.
