Programming and Parameters 3-49
COMMUNICATION (File H)
Masks & Owners
284 [MOP Mask]
Controls which adapters can issue MOP
commands to the drive.
See [Logic Mask]
. 288
thru
297
285 [Local Mask]
Controls which adapters are allowed to
take exclusive control of drive logic
commands (except stop). Exclusive “local”
control can only be taken while the drive is
stopped.
See [Logic Mask]
. 288
thru
297
288 [Stop Owner]
Adapters that are presently issuing a valid stop
command.
Read Only 276
thru
285
289 [Start Owner]
Adapters that are presently issuing a
valid start command.
See [Stop Owner]. 276
thru
285
290 [Jog Owner]
Adapters that are presently issuing a valid
jog command.
See [Stop Owner]
. 276
thru
285
291 [Direction Owner]
Adapter that currently has exclusive
control of direction changes.
See [Stop Owner]
. 276
thru
285
292 [Reference Owner]
Adapter that has the exclusive control of
the command frequency source selection.
See [Stop Owner]
. 276
thru
285
293 [Accel Owner]
Adapter that has exclusive control of
selecting [Accel Time 1, 2].
See [Stop Owner]
. 140
276
thru
285
294 [Decel Owner]
Adapter that has exclusive control of
selecting [Decel Time 1, 2].
See [Stop Owner]
. 142
276
thru
285
295 [Fault Clr Owner]
Adapter that is presently clearing a fault.
See [Stop Owner]
. 276
thru
285
296 [MOP Owner]
Adapters that are currently issuing
increases or decreases in MOP command
frequency.
See [Stop Owner]
. 276
thru
285
File H
Group
No.
Parameter Name and Description
See page 3-2 for symbol descriptions
Values
Related
0001x0xxxxxxxxxx
10 01234567891112131415
1 = Issuing Command
0 = No Command
x = Reserved
Bit #
Digital In
DPI Port 1
DPI Port 2
DPI Port 3
DPI Port 5
Nibble 1Nibble 2Nibble 3Nibble 4
To Next Page
