3-50 Programming and Parameters
COMMUNICATION (File H)
Masks & Owners
297 [Local Owner]
Adapter that has requested exclusive
control of all drive logic functions. If an
adapter is in local lockout, all other
functions (except stop) on all other
adapters are locked out and
non-functional. Local control can only be
obtained when the drive is not running.
See [Stop Owner]
. 276
thru
285
Datalinks
300
301
[Data In A1] - Link A Word 1
[Data In A2] - Link A Word 2
Parameter number whose value will be
written from a communications device
data table.
Parameters that can only be changed
while drive is stopped cannot be used as
Datalink inputs. Entering a parameter of
this type will “Disable” the link.
Refer to your communications option
manual for datalink information.
Default:
Min/Max:
Units:
0 (0 = “Disabled”)
0/387
0/545
0/598
1
302
303
[Data In B1] - Link B Word 1
[Data In B2] - Link B Word 2
See [Data In A1] - Link A Word 1.
304
305
[Data In C1] - Link C Word 1
[Data In C2] - Link C Word 2
See [Data In A1] - Link A Word 1.
306
307
[Data In D1] - Link D Word 1
[Data In D2] - Link D Word 2
See [Data In A1] - Link A Word 1.
310
311
[Data Out A1] - Link A Word 1
[Data Out A2] - Link A Word 2
Parameter number whose value will be
written to a communications device data
table.
Default:
Min/Max:
Units:
0 (0 = “Disabled”)
0/387
0/545
0/598
1
312
313
[Data Out B1] - Link B Word 1
[Data Out B2] - Link B Word 2
See [Data Out A1] - Link A Word 1.
314
315
[Data Out C1] - Link C Word 1
[Data Out C2] - Link C Word 2
See [Data Out A1] - Link A Word 1.
316
317
[Data Out D1] - Link D Word 1
[Data Out D2] - Link D Word 2
See [Data Out A1] - Link A Word 1.
308 [HighRes Ref]
Used as a high resolution, 32 bit
reference with Datalinks.
–/+[Maximum Freq] or
–/+[Maximum Speed] = 2147418112
Default:
Min/Max:
Units:
0
–/+2147483647
1
090
093
126
128
213
298
File H
Group
No.
Parameter Name and Description
See page 3-2 for symbol descriptions
Values
Related
E C
E C v2
E C
E C v2
32
E C
