3-40 Programming and Parameters
UTILITY (File E)
Diagnostics
212 [Drive Alarm 2]
Alarm conditions that currently exist in the drive.
Read Only 211
213 [Speed Ref Source]
Displays the source of the speed
reference to the drive.
(1)
Enhanced Control Drives Only.
Default:
Options: 0
1
2
3-7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23-29
30
Read Only
“PI Output”
“Analog In 1”
“Analog In 2”
“Reserved”
“Encoder”
“MOP Level”
“Reserved”
“Preset Spd1”
“Preset Spd2”
“Preset Spd3”
“Preset Spd4”
“Preset Spd5”
“Preset Spd6”
“Preset Spd7”
“DPI Port 1”
“DPI Port 2”
“DPI Port 3”
“Reserved”
“DPI Port 5”
“Reserved”
“HighRes Ref”
(1)
090
093
096
101
214 [Start Inhibits]
Displays the inputs currently preventing the drive from
starting.
Read Only
File E Group No.
Parameter Name and Description
See page 3-2 for symbol descriptions
Values
Related
000000000000000x
10 01234567891112131415
1 = Condition True
0 = Condition False
x = Reserved
Bit #
DigIn CflctA
DigIn CflctB
DigIn CflctC
Bipolr Cflct
MtrTyp Cflct
NP Hz Cflct
MaxFrq Cflct
VHz NegSlope
IR Vlts Rang
FlxAmps Rang
SpdRef Cflct
Ixo Volt Rang
(2)
Sleep Config
(2)
TB Ref Cflct
(1)
PTC Conflict
(1)
Nibble 1Nibble 2Nibble 3Nibble 4
x0xxxxxxxxxxxxxx
26 161718192021222324252728293031
1 = Condition True
0 = Condition False
x = Reserved
Bit #
UserSetCflct
(2)
Nibble 1Nibble 2Nibble 3Nibble 4
(1)
Enhanced firmware 1.001 & later.
(2)
Enhanced firmware 2.001 & later.
000000000000x0xx
10 01234567891112131415
1 = Inhibit True
0 = Inhibit False
x = Reserved
Bit #
Fault
Type 2 Alarm
Enable
DC Bus Pchrg
Stop Assertd
Params Reset
StartUp Actv
Safe Off
(1)
Digital In
DPI Port 1
DPI Port 2
DPI Port 3
Reserved
DPI Port 5
Nibble 1Nibble 2Nibble 3Nibble 4
(1)
Enhanced firmware 3.002 & later.
