Programming and Parameters 3-45
UTILITY (File E)
Faults
241 [Fault Clear Mode]
Enables/disables a fault reset (clear
faults) attempt from any source. This does
not apply to fault codes which are cleared
indirectly via other actions.
Default:
Options:
1
0
1
“Enabled”
“Disabled”
“Enabled”
242 [Power Up Marker]
Elapsed hours since initial drive power up.
This value will rollover to 0 after the drive
has been powered on for more than the
max value shown. For relevance to most
recent power up see [Fault x Time].
Default:
Min/Max:
Units:
Read Only
0.0000/429496.7295 Hrs
0.0001 Hrs
246
243
245
247
249
[Fault 1 Code]
[Fault 2 Code]
[Fault 3 Code]
[Fault 4 Code]
A code that represents the fault that
tripped the drive. The codes will appear in
these parameters in the order they occur
([Fault 1 Code] = the most recent fault).
Default:
Min/Max:
Units:
Read Only
0/9999
0/65535
0
244
246
248
250
[Fault 1 Time]
[Fault 2 Time]
[Fault 3 Time]
[Fault 4 Time]
Default:
Min/Max:
Units:
Read Only
0.0000/429496.7295 Hrs
0.0001 Hrs
242
The time between initial drive power up and the occurrence of the associated trip
fault. Can be compared to [Power Up Marker] for the time from the most recent
power up.
[Fault x Time] – [Power Up Marker] = Time difference to the most recent power up.
A negative value indicates fault occurred before most recent power up. A positive
value indicates fault occurred after most recent power up.
To convert this value to the number days, hours, minutes and seconds, the
following formula may be used:
Fault x Time / 24 hours = (# of days).(remaining time)
Remaining Time x 24 hours = (# of hours).(remaining time)
Remaining Time x 60 minutes = (# of minutes).(remaining seconds)
Remaining Time x 60 seconds = (# of seconds)
Result = (# of days).(# of hours).(# of minutes).(# of seconds)
Example: 1909.2390 Hrs / 1 Day/24 Hrs = 79.551625 Days
0.551625 Days x 24 Hrs/Day = 13.239 Hrs
0.239 Hrs x 60 Min/Hr = 14.34 Min
0.34 Min x 60 Sec/Min = 20.4 Secs
File E
Group
No.
Parameter Name and Description
See page 3-2 for symbol descriptions
Values
Related
32
E C
32
To Next Page
