INPUTS & OUTPUTS (File J)
Digital Outputs
380
384
[Digital Out1 Sel]
[Digital Out2 Sel]
Selects the drive status that will energize
a (CRx) output relay.
(1)
Any relay programmed as Fault or
Alarm will energize (pick up) when
power is applied to drive and
deenergize (drop out) when a fault or
alarm exists. Relays selected for other
functions will energize only when that
condition exists and will deenergize
when condition is removed. Refer to
page 1-14
.
(2)
Activation level is defined in [Dig Outx
Level] below.
(3)
Enhanced Control Drives Only.
(4)
Enhanced Firmware V3.002 and later.
Default:
Options:
1
4
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31-57
58
59
“Fault”
“Run”
“Fault”
(1)
“Alarm”
(1)
“Ready”
“Run”
“Forward Run”
“Reverse Run”
“Auto Restart”
“Powerup Run”
“At Speed”
“At Freq”
(2)
“At Current”
(2)
“At Torque”
(2)
“At Temp”
(2)
“At Bus Volts”
(2)
“At PI Error”
(2)
“DC Braking”
“Curr Limit”
“Economize”
“Motor Overld”
“Power Loss”
“Input 1 Link”
“Input 2 Link”
“Input 3 Link”
“Input 4 Link”
“Input 5 Link”
“Input 6 Link”
“PI Enabled”
(3)
“PI Hold”
(3)
“Drive Overld”
(3)
“Param Cntl”
(3)
““Reserved”
“Manual Mode”
(4)
“Fast Braking”
(4)
381
385
382
383
002
001
003
004
218
012
137
157
147
053
048
184
381
385
[Dig Out1 Level]
[Dig Out2 Level]
Sets the relay activation level for options
10 – 15 in [Digital Outx Sel]. Units are
assumed to match the above selection
(i.e. “At Freq” = Hz, “At Torque” = Amps).
Default:
Min/Max:
Units:
0.0
0.0
0.0/819.2
0.1
380
382
386
[Dig Out1 OnTime]
[Dig Out2 OnTime]
Sets the “ON Delay” time for the digital
outputs. This is the time between the
occurrence of a condition and activation of
the relay.
Default:
Min/Max:
Units:
0.0 Secs
0.0 Secs
0.0/600.0 Secs
0.1 Secs
380
File J
Group
No.
Parameter Name and Description
See page 3-2 for symbol descriptions
Values
Related
To Next Page
