Programming and Parameters 3-35
DYNAMIC CONTROL (File D)
Restart Modes
179 [Sleep Wake Ref]
Selects the source of the input controlling
the Sleep-Wake function.
Default:
Options:
2
1
2
“Analog In 2”
“Analog In 1”
“Analog In 2”
180 [Wake Level]
Defines the analog input level that will
start the drive.
Default:
Min/Max:
Units:
6.000 mA, 6.000 Volts
[Sleep Level]/20.000 mA
[Sleep Level]/10.000 Volts
0.001 mA
0.001 Volts
181
181 [Wake Time]
Defines the amount of time at or above
[Wake Level] before a Start is issued.
Default:
Min/Max:
Units:
1.0 Secs
0.0/1000.0 Secs
0.1 Secs
180
182 [Sleep Level]
Defines the analog input level that will
stop the drive.
Default:
Min/Max:
Units:
5.000 mA, 5.000 Volts
4.000 mA/[Wake Level]
0.000 Volts/[Wake Level]
0.001 mA
0.001 Volts
183
183 [Sleep Time]
Defines the amount of time at or below
[Sleep Level] before a Stop is issued.
Default:
Min/Max:
Units:
1.0 Secs
0.0/1000.0 Secs
0.1 Secs
182
Power Loss
177 [Gnd Warn Level]
Sets the level at which a ground warning
fault will occur. Configure with [Alarm
Config 1].
Default:
Min/Max:
Units:
3.0 Amps
1.0/5.0 Amps
0.1 Amps
259
184 [Power Loss Mode]
Sets the reaction to a loss of input power.
Power loss is recognized when:
• DC bus voltage is ≤ 73% of [DC Bus
Memory] and [Power Loss Mode] is
set to “Coast”.
• DC bus voltage is ≤ 82% of [DC Bus
Memory] and [Power Loss Mode] is
set to “Decel”.
Default:
Options:
0
0
1
2
“Coast”
“Coast”
“Decel”
“Continue”
013
185
185 [Power Loss Time]
Sets the time that the drive will remain in
power loss mode before a fault is issued.
Default:
Min/Max:
Units:
0.5 Secs
0.0/60.0 Secs
0.1 Secs
184
187 [Load Loss Level]
Sets the percentage of motor nameplate
torque at which a load loss alarm will
occur.
Default:
Min/Max:
Units:
200.0%
0.0/800.0%
0.1%
211
259
188 [Load Loss Time]
Sets the time that current is below the
level set in [Load Loss Level] before a fault
occurs.
Default:
Min/Max:
Units:
0.0 Secs
0.0/300.0 Secs
0.1 Secs
187
File D Group No.
Parameter Name and Description
See page 3-2 for symbol descriptions
Values
Related
E C v2
E C v2
E C v2
E C v2
E C v2
E C v2
E C
E C v2
E C v2
