EN
64
4 Updates of version P4.00
1. Added a selection to par. .
2. Added a selection to par.  and .
3. Improved phototest management.
4. Improved management of guaranteed closure.
5. Expanded the memory from 64k to 256k of FLASH in view of future developments.
5 Technical characteristics of product
AG/004
AG/006
KB/004
KB/006
BI/004HP
BI/006
BI/008
BI/004
AG/004/115
AG/006/115
KB/004/115
KB/006/115
BI/004HP/115
BI/006/115
BI/008/115
BI/004/115
MAINS POWER VOLTAGE 230 V
± 10% 50Hz 115V ± 10% 60Hz
MAXIMUM MAINS POWER ABSORPTION 240 W
FUSES
F1 = 10A (ATO257) motor power circuit protection
F2 = 4A (ATO257) electric lock protection
F3 = 3A (ATO257) accessories power supply protection
F4 = T1A (5x20 mm)
primary transformer coil
protection
F4 = T2A (5x20 mm)
primary transformer coil
protection
NUMBER OF CONNECTABLE MOTORS 1
MOTOR POWER SUPPLY 36 V
MOTOR TYPE sinusoidal drive brushless (ROGER BRUSHLESS)
MOTOR CONTROL TYPE WIRWSVIH[MXLƼIPHSVMIRXIHGSRXVSP*3'
MAXIMUM MOTOR POWER 220 W
MAXIMUM POWER, EXTERNAL FLASHING
LIGHT
5 W 24 V
MAXIMUM POWER, BARRIER LIGHTS 12 W 24 V
MAXIMUM POWER, ELECTRIC LOCK
10W 12V
(impulse activation, 1.5 seconds) *
5W 12V
(normally powered electric lock) *
MAXIMUM POWER, INDICATOR LAMP 3 W 24 V
ACCESSORY OUTPUT POWER 10 W 24 V
OPERATING TEMPERATURE
-20°C +55°C
SOUND PRESSURE DURING USE <70 dB(A)
PRODUCT DIMENSIONS (MQIRWMSRWMRQQ\\;IMKLX/K
B73/EXP
RELAY CONTACT NC 2x 30 V
1A (potential free contact, resistive load)
(*) The electric lock output provides a voltage of 36Vdc nominal (max 40Vdc) modulated to 30% (30% ON, 70% OFF).
The device to be connected must therefore be able to withstand a maximum voltage of 40Vdc.
