(00-99 sec./min.)
counts down for unlimited period till moment
when reader changes it arming mode.
10
Duress Alarm
(00-99 sec./min.)
3 min
Defines duration time for Duress Alarm.
Programming timer to 00s makes that timer
counts down for unlimited period till moment
when reader changes it arming mode.
11
LED STATUS Masking
(01-99 sec./min.)
20 s
Defines duration time for LED STATUS before it
will switch to neutral mode when it lights up in
red and green alternatively.
5.15. OPTICAL AND ACOUSTIC SIGNALS
LED Signals
LED
STATUS
LED
OPEN
LED
SYSTEM
Description
Green
—
—
Reader is disarmed.
Red
—
—
Reader is armed.
Red
ON
—
Reader is in User Programming mode.
Green
ON
—
Reader is in Installer Programming mode.
—
—
Flashing
During programming: reader is waiting for the user to
enter the next part of the command or programming
function.
Flashing
During normal operation: reader is waiting for a TOGGLE
user to enter his identifier once again in order to change
reader’s arming mode.
—
—
Single
flash
A user identifier (Card or PIN) has been entered.
—
ON
—
The door lock is activated, this LED remains on as long as
a door is unlocked.
—
Flashing
—
Reader is waiting for the PIN (when Card and PIN mode
is valid).
ON
Door is being unlocked (lock released).
—
—
ON
When LED SYSTEM is lit and accompanied with short
beep periodically repeated it means that either
configuration memory is corrupted or MASTER and
INSTALLER identifiers are not programmed yet. In this
case reader must be totally reprogrammed.
When LED SYSTEM is lit and no sound is generated it
means that error in firmware was detected. To fix this
problem the proper firmware must be uploaded into the
reader.
