Readers can be configured for Standalone Mode (Offline Mode) or Terminal Mode (Online Mode)
when they are connected to the external access control unit (ACU) supporting compatible data
interface formats.
When configured for standalone operation PRTxxEM reader independently (i.e. autonomously)
controls the supervised door access point. For this mode reader offers two variants of installation:
first of them uses the reader’s built-in I/O signal lines as programmable inputs and outputs, the
second one uses them for communication with external XM-2 expander and secondary (optional)
PRT series reader. An access control installation including two PRT readers (one at the entry and
other at the exit side of the supervised door) enables read-in/out door control. Also, the system
setup utilizing the XM-2 expander provides higher level of security for the entire door access
control system by separating its logical element (reader) from the relay which physically controls
door lock.
The PRTxxEM reader configured for Online Mode works as a slave unit for the purpose of reading
cards/PIN-s then providing subsequent transmission of such collected data to host ACU for further
processing. Reader offers several data transmission formats including popular Wiegand and
Magstripe data protocols.
The PRTxxEM reader can be also used to program T5555 (Q5) and T5557 type cards using RARC
software.
3.1. FEATURES
3.1.1. General
EM 125 KHz proximity cards (EM4100/4102 compatible)
Programmable T5555 (Q5) and T5557 card numbers
Tamper switch (detection of enclosure opening and detachment)
Configurable as standalone access unit or slave reader
Outdoor installation (depends on particular reader)
Programming and firmware upgrade through RS232 serial port
RARC configuration program (for Windows)
3.1.2. Terminal Mode (Online Mode)
26/32/32 reversed/34/42/66 bit Wiegand data formats
Magstripe data format (ABA Track II emulation)
RACS CLK/DTA (for communication with Roger controllers)
RS232, EPSO protocol
RS232, direct output of cards and keys
RS232, direct output of cards and PIN-s
Various options for transmission of PIN-s and keys
LED control input
BUZZER control input
3.1.3. Standalone Mode (Offline Mode)
System settings stored in non-volatile memory
120 indexed users with card and/or PIN-s
User indexing (indexed user records)
Card or PIN or Card and PIN identification modes
Real time clock (100 year)
Automatic winter/summer time change
1000 event log
Built-in 1.5A relay output
Support for door contact and exit button
Read-in/read-out door control (requires second PRT reader)
Door Alarm and Door Bell signalling
Integration with the alarm system trough I/O-s
Operation with XM-2 I/O expander (Full Standalone Mode)
