8. I N S T A L L E R P R O G R A M M I N G
Use this mode to configure various functionalities of the reader. Alternatively all Installer
Programming settings can be entered with RARC software after connection of reader to computer.
You can enter this mode by using INSTALLER card or entering INSTALLER PIN. Once in this mode
the LED OPEN (green) turns on and LED STATUS lights in green.
8.1. PROGRAMMING COMMANDS
[53][EF] – Programming Function for CLK/REL1, EF=11, 21..27, 41..64, default: EF=41
This EF digits define the function for CLK line (when reader is configured for Simple Standalone
Mode) or for REL1 output on XM-2 expander (when reader is configured for Full Standalone
Mode). The CLK line can operate as input or output while REL1 always works as output. For I/O
function codes see section Input/Output Functions.
Note: It is forbidden to program two or more inputs to the same function. This restriction is not
valid for outputs. Reader indicates error when attempting to program two inputs to the same
function.
[54][EF] – Programming function for DTA/REL2, EF=11, 21..27, 41..64, default: EF=44
This command sets the function for DTA line (when reader is configured for Simple Standalone
Mode) or for REL2 output on XM-2 expander (when reader is configured for Full Standalone
Mode). The DTA line can operate as input or output while REL2 always works as output.
[55][GH] – Programming function for IN1, GH=11, 21..27, default: GH=21
This command sets the function for IN1 input line located on the reader.
[56][GH] – Programming function for IN2, GH=11, 21..27, default: GH=11
This command sets the function for IN2 input line located on the reader.
[57][GH] – Programming function for IN1 on XM-2 expander,
GH=11, 21..27, default: GH=22
This command sets the function for IN1 input located on the remote XM-2 expander.
[58][GH] – Programming function for IN2 on XM-2 expander,
GH=11, 21..27, default GH=23
This command sets the function for IN2 input located on the remote XM-2 expander.
[59][J] – Programming Identification Mode for primary reader, J=0..1, default: J=0
This command sets the Identification Mode for the primary reader. Program J=0 for Card or
PIN mode or J=1 for Card and PIN mode.
[60][J] – Programming Identification Mode for secondary reader, J=0..1, default: J=0
This command sets the Identification Mode for the secondary (external) reader. Program J=0 for
Card or PIN mode or J=1 for Card and PIN mode.
[61][J] – Programming option “Door Alarm indication on internal buzzer”, J=0..1,
default: J=0
When J=0 reader will not signal Door Alarm on internal buzzer, when J=1 Door Alarm will be
signaled on output (if programmed) and buzzer as well.
[62][J] – Programming option “Access disabled when reader armed”, J=0..1, default:
J=0
When J=0 reader will grant access both if it is in armed or disarmed mode, for J=1 access can be
granted only in disarmed mode.
