Roger PRT12EM - Operation with XM-2 I;O Expander; Operation with Second PRT Series Reader; 6 Programming

PRTxxEM series readers Operating Manual.doc 2018-08-21
21/54
Acoustic Signals
Signal
Symbol
Description
One long signal
-
Error - unknown identifier, access denied.
Three short
beeps
* * *
Command successfully completed (OK signal).
Two short beeps
* *
Prompt signal, the reader is waiting for the next
part of the command to be entered. This signal is
intended to encourage the programmer to proceed
with next programming steps.
Long beep
continuously
repeated
- - - - - - …
Reader has detected problem (either configuration
memory is corrupted and reader must be
reconfigured anew). This signal is accompanied by
the steady lit LED SYSTEM .
Legend: - long beep, * beep
5.16. OPERATION WITH XM-2 I/O EXPANDER
In Full Standalone Mode, reader can be connected with XM-2 I/O expander. Each input and
output of the XM-2 can be programmed in the same way as internal inputs and outputs of the
reader. The XM-2 should be connected to the reader’s CLK and DTA lines and must have address
set to ID=5. The maximum distance between the reader and XM-2 expander is limited to 150 m.
Note: The XM-2 expander has two red LED-s which are intended to indicate triggering of
corresponding relay output (REL1 or REL2) and one green LED which lights continuously when
communication with host reader is working and blinking when broken.
5.17. OPERATION WITH SECOND PRT SERIES READER
In Full Standalone Mode, the main PRTxxEM reader can operate with second PRT series reader,
even if it works with another card standard (e.g. Mifare). The access system with two readers using
different card technologies can be used for installations with two card technologies. The second PRT
reader should be connected with main (primary) reader and configured with RACS address ID=0
operating mode. The pair of two readers can be used for read-in/out door control or for manual
programming when the main reader is not equipped with keypad. The maximum distance between
primary and secondary PRT reader is limited to 150 m.
Note: The LED-s and buzzer on secondary reader copy (imitate) the LED-s/buzzer of primary
reader.
6. P R O G R A M M I N G
The reader can be programmed:
 From the PC with RARC program (RS232)
 From the keypad located on the main reader
 From the keypad located on the external (secondary) reader
 Through multiple reading of the so called Programming Card
Preparing the Reader for Terminal Mode (Online mode)
If the unit is dedicated for Terminal Mode (slave operation), then it is only necessary to program
[000]..[003] operating mode. It can be done either manually during Memory Reset or remotely
from PC.
