PRTxxEM series readers Operating Manual.doc 2018-08-21
31/54
Programs PIN and card for Installer user. Optionally, program [82][PIN][#][#] to omit card
programming or [82][Card] to omit PIN programming.
[83][S][KL] – Programming “Pulse on Arming” timer, S=0..1, KL=01..99, default: S=0
KL=02
This timer defines duration time for pulse generated on [52] function output. Program S=0 for
seconds or S=1 for minutes.
[84][S][KL] – Programming “Pulse on Disarming” timer, S=0..1, KL=01..99, default: S=0
KL=02
This timer defines duration time for pulse generated on [53] function output. Program S=0 for
seconds or S=1 for minutes.
[85][S][KL] – Programming “Pulse on Arming/Disarming” timer, S=0..1, KL=01..99,
default: S=0 KL=02
This timer defines duration time for pulse generated on [54] function output. Program S=0 for
seconds or S=1 for minutes.
[#] - Exit from Installer Programming mode
Reader leaves Installer Programming mode and returns to normal operation (either Armed or
Disarmed) depending on the state it was before.
Note: If you don’t press any key for 1 min then reader will automatically leave the Installer
Programming mode.
8.2. INPUT/OUTPUT FUNCTIONS
Input/output Functions
Code
Name
Description
11
Line Off
Line is disabled and reader ignores electrical states on this
line.
21
Door Contact
Input, when shorted with supply minus indicates that
controlled door is closed.
22
Exit Button
Input, shorting this line with supply minus triggers [41]:
Door Lock and [42]: Exit Door Lock outputs (when
programmed) for time specified by Door Unlock Time. This
input doesn’t activate [43]: Entry Door Lock.
23
Arming Disabled
Input, as long as line is shorted with supply minus reader
disables TOGGLE and TOGGLE LTD user from switching the
reader into Armed mode.
24
Arming/Disarming
Key Switch
Input, when line is shorted to supply minus reader switches
unconditionally to Disarmed mode, when line is open reader
returns and stay in Armed mode.
25
LED STATUS
Input, when programmed it controls LED STATUS and this
LED no longer presents current arming mode of the reader.
When line is shorted to supply minus LED STATUS lights in
green, when open lights in red.
26
Tamper
Input, normally closed, opening this input (no matter in
Armed mode or in Disarmed mode) will start Tamper
Alarm and General Alarm.
27
Intruder
Input, normally closed to supply minus, opening this input
during Armed mode will start Intruder Alarm and General
Alarm.
