Roger PRT12EM - Page 32

PRTxxEM series readers Operating Manual.doc 2018-08-21
32/54
28
Buzzer Control
Input, when shorted with supply minus activates buzzer.
29
LED OPEN Control
Input, when shorted with supply minus activates LED OPEN.
41
Door Lock
Output, whenever access is granted (no matter from primary
or secondary or through exit button), this output is triggered
for time specified by Door Unlock Time.
42
Exit Door Lock
Output, triggered whenever access is granted from primary
(main) reader or by triggering of the [22]: Exit Button
input, once triggered it goes on for time specified by Door
Unlock Time. It is not activated when access is granted
from secondary reader. This output is dedicated for rotary
gates when two opening outputs (for clockwise and
anticlockwise movement) are necessary
43
Entry Door Lock
Output, triggered whenever access is granted from secondary
(external) reader, this output goes on for time specified by
Door Unlock Time. It is not activated when access is
granted from primary reader or from exit button input. This
output is dedicated for rotary gates when two opening
outputs (for clockwise and anticlockwise movement) are
necessary.
44
Disarmed Mode
Output, line remains active as long as reader is disarmed.
45
Armed Mode
Output, line remains active as long as reader is armed.
46
Door Alarm
Output, line is used to indicate Door Alarm and is modulated
according to detected type of alarm, when more than one
alarm exists output signals alarm with the highest priority.
47
Door Bell
Output, signals door bell for approx. 5 seconds.
48
AUX1 Toggle
Output, whenever F1 is pressed this output switches to
opposite state regardless of the setting of AUX1 Timer.
49
AUX2 Toggle
Output, whenever F2 is pressed this output switches to
opposite state regardless of the setting of AUX2 Timer.
50
AUX1 Momentary
Output, line is activated for predefined time when F1 key is
pressed. The activation time is specified by AUX1 Timer.
When AUX1 Timer is set to 00s output it activated for
unlimited time - till moment when reader changes its arming
mode again.
51
AUX2 Momentary
Output, line is activated for predefined time when F2 key is
pressed. The activation time is specified by AUX2 Timer.
When AUX2 Timer is set to 00s output it activated for
unlimited time - till moment when reader changes its arming
mode again.
52
Pulse on Arming
Output, line is activated for predefined time whenever reader
is switched to armed mode. Activation time is defined by
Pulse on Arming Timer.
53
Pulse on Disarming
Output, line is activated for predefined time whenever reader
is switched to disarmed mode. Activation time is defined by
Pulse on Disarming Timer.
54
Pulse on Arming and
Disarming
Output, line is activated for predefined time whenever reader
changes its arming mode. Activation time is defined by Pulse
on Arming/Disarming Timer.
55
Tamper Alarm
Output, line is triggered in the moment when Tamper Alarm
is raised. Output remains active for time defined by Tamper
