Rohde & Schwarz CMU 200 Service Manual

Für diese Unterlage behalten wir uns alle Rechte vor.
Ausgedruckte Dokumente unterliegen nicht dem Änderungsdienst.
For this document all rights are reserved.
Printed documents are not subject to revision
_
Pos.-Nr.
ItemNo
Menge
Quantity
ME
Unit
El.Kennz
Ref.Des.
Benennung / Bezeichnung
Designation
Z Sachnummer
Stock No.
Ersatzteil
Subst.part
BA VH
Benennung/Designation
ERSATZTEILE CMU
SPARE PARTS CMU
Sprach./Lang
de en
Ä.I. / C.I
18.00
Blatt/Sheet
3 of 12
Dokument Nr. / Document No.
1100.0114.01 ST
Datum/
Date
2006-06-19
Abt. /
Dept.
1CMK
Name /
Name
GL
250 1 S A14 BP TFT 8.4 VGA DRGB CCFL 0048.6980.00 B V
8.4 COLOR LCD MODULE
included in 1090.9244.12/22/23/24
251 1 S E10 DX LUEFTEREINHEIT 1091.0292.00 M
FAN UNIT
included in 1090.9244.12/22/23/24
252 1 S GR LUEFTER F. FMR5+ / 6+ 1091.2943.00 B O
BLOWER F. FMR5+ / 6+
included in 1090.9244.12/22/23
253 1 S T3 BP CXA-L0605-VJL DC-AC 0048.6996.00 B T
DC TO AC INVERTER UNIT
included in 1090.9244.12/22/23/24
255 1 S OP FILTERSCHEIBE GESCHIR. 1091.2014.00 B V
SCREENED FILTER GLASS
included in 1090.9244.12/22/23/24
256 2 S MZ HF-FEDER (177) Z 1069.3011.00 M
RF SPRING
included in 1090.9244.12/22/23/24
257 2 S MZ HF-FEDER (137) Z 1069.3105.00 M
RF SPRING
included in 1090.9244.12/22/23/24
258 4 S MM SCHEIBENHALTER 0852.0844.00 M
DISK HOLDER
included in 1090.9244.12/22/23/24
259 1 S OK DREH.RD28 ACHS-RD6 0852.1086.00 B T
KNOB
included in 1090.9244.12/22/23/24
260 1 S D1 ZE HARD DISK PROGR. CMU Z 1100.0989.00 M
HARD DISK PROGR. CMU
261 1 S MZ STAUBABDICHTUNG Z 1093.5279.00 M
DUST COVER
included in 1090.9244.22/23/24
300 0 S A3 EE RX/TX BOARD Z 1100.1404.02 M
RX/TX BOARD
Replaced by 1100.1733.02
Adjustment with ACS114 necessary
301 0 S A3 EE RX/TX BOARD Z 1100.1733.02 M
RX/TX BOARD
Replaced by 1135.6702.02
Adjustment with ACS114 necessary
302 0 S A3 EE RX/TX BOARD Z 1135.6702.02 M
RX/TX BOARD
Replaced by 1135.6925.02
Adjustment with ACS114 necessary
303 1 S A3 EE RX/TX BOARD Z 1135.6925.02 M
RX/TX BOARD
Adjustment with ACS114 necessary
310 1 S EP 1842.5MHZ-BANDPASS-FI. 1100.4255.00 B O
BANDPASS FILTER
Included in 1100.1404.02, 1100.1733.02,
1135.6702.02, 1135.6925.02
311 1 S EP 836.5MHZ-BANDPASS-FI. 1100.4261.00 B O
BANDPASS FILTER
Included in 1100.1404.02, 1100.1733.02,
1135.6702.02, 1135.6925.02
312 1 S EP 10.7MHZBANDP.KER.B350K 1100.4661.00 B O
10.7MHZ CERAMIC BANDPASS
