Rohde & Schwarz CMU 200 Service Manual

Für diese Unterlage behalten wir uns alle Rechte vor.
Ausgedruckte Dokumente unterliegen nicht dem Änderungsdienst.
For this document all rights are reserved.
Printed documents are not subject to revision
_
Pos.-Nr.
ItemNo
Menge
Quantity
ME
Unit
El.Kennz
Ref.Des.
Benennung / Bezeichnung
Designation
Z Sachnummer
Stock No.
Ersatzteil
Subst.part
BA VH
Benennung/Designation
ERSATZTEILE CMU
SPARE PARTS CMU
Sprach./Lang
de en
Ä.I. / C.I
18.00
Blatt/Sheet
4 of 12
Dokument Nr. / Document No.
1100.0114.01 ST
Datum/
Date
2006-06-19
Abt. /
Dept.
1CMK
Name /
Name
GL
Included in 1100.1404.02, 1100.1733.02,
1135.6702.02
313 1 S EP 479.75MHZ SAW-BP 1100.4278.00 B V
SAW FILTER
Included in 1100.1404.02, 1100.1733.02,
1135.6925.02
314 1 S ER KERAMIK RESONATOR 550M 1100.4426.00 B V
CERAMIC RESONATOR
Included in 1100.1404.02, 1100.1733.02,
1135.6702.02, 1135.6925.02
320 1 S EE TR-CORRECTION MODULE Z 1100.1604.02 M
TR-CORRECTION MODULE
included in 1100.1404.02
included in 1100.1733.02
included in 1135.6702.02
included in 1135.6925.02
330 1 S EE RX IF3 MODULE Z 1135.6983.02 M
included in 1135.6925.02
700 0 S A7 ZE DIGITAL UNIT Z 1100.1791.02 M
DIGITAL UNIT
ZE Digital Board
(ZE = complete assembled module)
Replaced by 1100.1791.04
Adjustment with ACS114 necessary
701 0 S A7 ZE DIGITALBOARD Z 1100.1791.04 M
DIGITAL BOARD
ZE Digital Board
(ZE = complete assembled module)
Replaced by 1100.1940.04
Adjustment with ACS114 necessary
702 0 S A7 ZE DIGITALTEIL 2 Z 1100.1940.04 M O
DIGITAL UNIT 2
ZE Digital Board
(ZE = complete assembled module)
Replaced by 1100.1940.06
Adjustment with ACS114 necessary
703 1 S A7 ZE DIGITALTEIL 2 Z 1100.1940.06 M O
DIGITAL UNIT 2
ZE Digital Board
(ZE = complete assembled module)
Adjustment with ACS114 necessary
704 0 S PB BEMERKUNG 0999.9610.00 B O
NOTE
Attention: For detailed information reg.
different modules
in ZE Digital Board please refer to service
circular No. 1636
705 0 S A700 EE DIGITAL BOARD Z 1100.1804.02 M
DIGITAL BOARD
Digital Board (Baseboard)
Included in ZE Digital Board 1100.1791.02
Replaced by 1100.1804.04
Only in combination with ADC Module
1100.2200.02
706 0 S A700 EE DIGITAL BOARD Z 1100.1804.04 M
DIGITAL BOARD
Digital Board (Baseboard)
Included in ZE Digital Board 1100.1791.04
Only in combination with WADC Module
1100.2275.02
707 1 S A700 EE DIGITAL BOARD 2 Z 1100.1956.04 M
DIGITAL BOARD 2
Digital Board (Baseboard)
