Rohde & Schwarz CMU 200 Service Manual

Für diese Unterlage behalten wir uns alle Rechte vor.
Ausgedruckte Dokumente unterliegen nicht dem Änderungsdienst.
For this document all rights are reserved.
Printed documents are not subject to revision
_
Pos.-Nr.
ItemNo
Menge
Quantity
ME
Unit
El.Kennz
Ref.Des.
Benennung / Bezeichnung
Designation
Z Sachnummer
Stock No.
Ersatzteil
Subst.part
BA VH
Benennung/Designation
ERSATZTEILE CMU
SPARE PARTS CMU
Sprach./Lang
de en
Ä.I. / C.I
18.00
Blatt/Sheet
5 of 12
Dokument Nr. / Document No.
1100.0114.01 ST
Datum/
Date
2006-06-19
Abt. /
Dept.
1CMK
Name /
Name
GL
Included in ZE Digital Board 1100.1940.04/06
Only in combination with WADC Module
1100.2275.02
710 0 S A710 EE DDC MODULE Z 1100.2300.03 M
DDC MODULE
Included in ZE Digital Board
1100.1791.02/04, 1100.1940.04
Replaced by 1100.3220.02
711 0 S EE DDC400 MODULE Z 1100.3459.02 M
DDC400 MODULE
included in CMU-U65 1100.7402.02
712 1 S A710 EE WDDC400 MODULE Z 1100.3220.02 M
WDDC400 MODULE
Included in ZE Digital Board 1100.1940.06
Included in CMU-U65, CMU-U75
720 0 S A720 EE ADC MODULE Z 1100.2200.02 M
ADC MODULE
Included in ZE Digital Board 1100.1791.02
Replaced by 1100.2275.02
721 1 S A720 EE WADC MODULE Z 1100.2275.02 M
WADC MODULE
Included in ZE Digital Board 1100.1791.04,
1100.1940.04/06
Only in combination with Digital-Baseboard
1100.1804.04 and 1100.1956.04
Adjustment with ACS114 necessary
750 0 S A750 EE TXDSP MODULE Z 1100.2100.03 M
TXDSP MODULE
Included in ZE Digital Board 1100.1791.02/04
Replaced by 1100.2130.02
751 1 S A750 EE TXDSP MODULE Z 1100.2130.03 M
TXDSP MODULE
Included in ZE Digital Board
1100.1791.02/04, 1100.1940.04/06
760 1 S A760 ED AUC_MODULE Z 1100.2500.02 M
AUC MODULE
Included in ZE Digital Board
1100.1791.02/04, 1100.1940.04/06
Adjustment with ACS114 necessary
1000 0 S A100 GJ NETZTEIL 230W UL/CSA 1091.2320.00 B V
POWER SUPPLY
Replaced by 1091.1982.00
1010 1 S A100 GJ NETZTEIL 250W UL/CSA 1091.1982.00 B V
POWER SUPPLY
Please see service circular No. 1583 !
1011 1 S DF KABEL L=400 1149.9596.00 B O
CABLE
1020 0 S A20 ED RF FRONTEND Z 1100.3042.02 M
RF FRONTEND
Replaced by 1100.3120.02
Adjustment with ACS114 necessary
Old FE 1100.3042.04 was not used in CMU-
B/U99
1021 1 S A20 ED RF_FRONTEND Z 1100.3120.02 M
RF FRONTEND
VAR 02 03 10 53
Adjustment with ACS114 necessary
1025 1 S A20 ED RF-FRONTEND Z 1100.3120.04 M
RF-FRONTEND
VAR 30
Included in CMU-B/U99
