Rohde & Schwarz CMU 200 Service Manual

Für diese Unterlage behalten wir uns alle Rechte vor.
Ausgedruckte Dokumente unterliegen nicht dem Änderungsdienst.
For this document all rights are reserved.
Printed documents are not subject to revision
_
Pos.-Nr.
ItemNo
Menge
Quantity
ME
Unit
El.Kennz
Ref.Des.
Benennung / Bezeichnung
Designation
Z Sachnummer
Stock No.
Ersatzteil
Subst.part
BA VH
Benennung/Designation
ERSATZTEILE CMU
SPARE PARTS CMU
Sprach./Lang
de en
Ä.I. / C.I
18.00
Blatt/Sheet
6 of 12
Dokument Nr. / Document No.
1100.0114.01 ST
Datum/
Date
2006-06-19
Abt. /
Dept.
1CMK
Name /
Name
GL
Fixed part of CMU200/MOD30
Adjustment with ACS114 necessary
1100 1 S A10 EE REFERENCE BOARD Z 1100.2600.02 M
REFERENCE BOARD
1102 1 S A102 ED PCMCIA INTERFACE Z 1100.5616.02 M
PCMCIA INTERFACE
1103 1 S MM KARTENEINLASS F.M.CARD Z 1047.2006.00 B O
SLOT F.MEMORYCARD
1110 1 S A102 GM 3.5 ZOLL FLOPPY DRIVE SLIM 1091.2072.00 B N
FLOPPY DRIVE 3.5INCH
included in CMU-U61 1100.5500.02
1111 1 S MF FLOPPYRAHMEN 1091.1318.00 M
included in CMU-U61 1100.5500.02
1112 1 S MZ FLOPPYHALTER 1091.1353.00 M
included in CMU-U61 1100.5500.02
1113 1 S DF FLEX-STRIPVERB.26P.R=1 1091.2066.00 B O
FLEX-STRIP
included in CMU-U61 1100.5500.02
1200 0 S A200 ED MOTHERBOARD-SET Z 1100.1027.02 M
MOTHERBOARD
Replaced by 1100.0908.02
1201 0 S A200 ED MOTHERBOARD-SET Z 1100.0908.02 M
MOTHERBOARD
Fits only in combination with old frame
1090.9209.00.
Replaced by 1100.2352.02
(In combination with new frame
1090.9221.00)
1202 1 S A200 ED MOTHERBOARD CMU Z 1100.2352.02 M
MOTHERBOARD CMU
Fits only in combination with new frame
1090.9221.00
2205 1 S A205 ED OCXO REFERENCE OSC. Z 1100.2900.02 M
OCXO REFERENCE OSC.
Included in CMU-B11
2206 1 S A205 ED OCXO REFERENCE OSC.CMUB12 Z 1100.2900.03 M
OXCO REFERENCE OSC.
Included in CMU-B12
2300 0 S EE IQ/IF- INTERFACE BOARD Z 1135.6002.03 M
IQ/IF- INTERFACE BOARD
included in CMU-B17
2301 1 S EE IQ/IF- INTERFACE BOARD Z 1135.6125.03 M
IQ/IF- INTERFACE BOARD
included in CMU-B17
2400 0 S A8 A9 ZE UNIVERS. SIGN. UNIT Z 1100.5216.02 M
included in old CMU-B21
Replaced by 1100.5216.03
2401 1 S A8 A9 ZE UNIVERS. SIGN. UNIT Z 1100.5216.03 M
included in CMU-B21/MOD02
2410 1 S A400 EE LINK HANDLER Z 1097.3570.02 M
LINK HANDLER
included in CMU-B21/MOD02
2420 1 S A430 EE I/Q OUT MODULE Z 1100.2000.02 M
I/Q OUT MODULE
included in CMU-B21/MOD02
