Rohde & Schwarz CMU 200 Service Manual

Für diese Unterlage behalten wir uns alle Rechte vor.
Ausgedruckte Dokumente unterliegen nicht dem Änderungsdienst.
For this document all rights are reserved.
Printed documents are not subject to revision
_
Pos.-Nr.
ItemNo
Menge
Quantity
ME
Unit
El.Kennz
Ref.Des.
Benennung / Bezeichnung
Designation
Z Sachnummer
Stock No.
Ersatzteil
Subst.part
BA VH
Benennung/Designation
ERSATZTEILE CMU
SPARE PARTS CMU
Sprach./Lang
de en
Ä.I. / C.I
18.00
Blatt/Sheet
7 of 12
Dokument Nr. / Document No.
1100.0114.01 ST
Datum/
Date
2006-06-19
Abt. /
Dept.
1CMK
Name /
Name
GL
2430 0 S A440
A450
A460
A470
A1101
EE DSP MODULE Z 1097.3106.03 M
included in old CMU-B21
included in old CMU-B41
Replaced by 1097.3129.03
2431 1 S A440
A450
A460
A470
A1101
EE DSP MODUL Z 1097.3129.03 M
DSP MODULE
included in CMU-B21/MOD02,
CMU-B41 and CMU-B52/MOD02
2440 1 S A420 EE SPEECH INTERFACE Z 1100.2730.02 M
SPEECH CODEC
included in CMU-B52/MOD02
2450 1 S EE CMU BLUETOOTH ULH Z 1135.6502.02 M
CMU BLUETOOTH
included in CMU-B53/MOD02 and
CMU-U53/MOD02
2460 1 S A410 EE RAM-MODUL Z 1097.3158.02 M
RAM MODULE
included in CMU-B71
2500 1 S A9 ZE UNIVERS. SIGN. UNIT Z 1135.4497.02 M
UNIVERS. SIGN. UNIT
included in CMU-B21/MOD14
2501 1 S A9 ZE UNIVERS. SIGN. UNIT Z 1135.4497.14 M O
UNIVERS. SIGN. UNIT
included in CMU-B21/MOD54,
CMU-U21/MOD14
2510 1 S EE UNIVERSAL SIGNAL UNIT Z 1135.4500.02 M
UNIVERSAL SIGNAL UNIT
included in CMU-B21/MOD14,54, CMU-
U21/MOD14
2520 1 S EE SPEECH CODEC Z 1135.6102.02 M
SPEECH CODEC
included in CMU-B52/MOD14
2530 1 S EE BLUETOOTH Z 1135.6202.02 M
BLUETOOTH
included in CMU-B53/MOD14
2540 1 S EE MC 68K Z 1135.4700.02 M
MC 68K
included in CMU-B21/MOD54,
CMU-U21, CMU-B54
2550 1 S EE DSP MODULE 56311 Z 1135.4600.03 M
DSP MODULE 56311
included in CMU-B21/MOD54, CMU-U21,
CMU-B54, CMU-B55
2560 1 S EE POWER QUICC II MODUL Z 1122.9737.22 M
POWER QUICC II MODUL
included in CMU-B56/MOD14
2561 1 S EE POWER QUICC III MODUL Z 1503.1044.22 M
POWER QUICC III MODUL
included in CMU-B56/MOD54,
CMU-U56
2600 1 S EE AUDIO BOARD Z 1100.2800.02 M
AUDIO BOARD
