Rohde & Schwarz CMU 200 Service Manual

R&S CMU Test Report
1100.4903.82 1.25 E-5
Item
No.
Description
Measure-
ment
to section
Min. Actual Max.
Measurement
uncertainty
Unit
TX Level Settling Time
TX Level settling time
at P = +10 dBm to P = 0.5 dB
TX level
settling time
4
µs
TX Level settling time
at P = –20 dBm to P = 0.5 dB
4
µs
TX Level settling time
at P = –50 dBm to P = 0.5 dB
4
µs
TX Harmonics
TX 2nd harmonic at RF2 at carrier
frequency = 10 MHz
TX
harmonics
–30 dBc
TX 2nd harmonic at RF2 at carrier
frequency = 900 MHz
–30 dBc
TX 2nd harmonic at RF2 at carrier
frequency = 1800 MHz
–30 dBc
TX 2nd harmonic at RF2 at carrier
frequency = 2200 MHz
–30 dBc
TX 3rd harmonic at RF2 at carrier
frequency = 10 MHz
–30 dBc
TX 3rd harmonic at RF2 at carrier
frequency = 900 MHz
–30 dBc
TX 3rd harmonic at RF2 at carrier
frequency = 1800 MHz
–30 dBc
TX 3rd harmonic at RF2 at carrier
frequency = 2200 MHz
–30 dBc
TX 2nd harmonic at RF3 OUT at
carrier frequency = 10 MHz
–20 dBc
TX 2nd harmonic at RF3 OUT at
carrier frequency = 900 MHz
–20 dBc
TX 2nd harmonic at RF3 OUT at
carrier frequency = 1800 MHz
–20 dBc
TX 2nd harmonic at RF3 OUT at
carrier frequency = 2200 MHz
–20 dBc
TX 3rd harmonic at RF3 OUT at carrier
frequency = 10 MHz
–20 dBc
TX 3rd harmonic at RF3 OUT at carrier
frequency = 900 MHz
–20 dBc
TX 3rd harmonic at RF3 OUT at carrier
frequency = 1800 MHz
–20 dBc
TX 3rd harmonic at RF3 OUT at carrier
frequency = 2200 MHz
–20 dBc
TX In-band Spurious Responses
TX In-band spurious
R&S CMU setting = 460.9 MHz
search freq. ± (5 to 500) kHz from
carrier
TX in-band
spurious
responses
–40 dBc
